Dirt Devil Libero - Overview; Scope of Delivery

28
1Overview
1Overview
1.1 Scope of delivery
1 Charging indicator light “ ”:
- Flashes blue, when the battery pack
charging
- Is continuously illuminated blue when
the battery pack is charged
- In operation flashes alternately with
""
2 Cleaning indicator “ ”:
- Is illuminated red when the dust contain-
er must be emptied
3 Battery indicator " ":
- Is illuminated red, when the battery pack
must be charged or if the appliance has
no floor contact
- In operation flashes alternately with
""
4 Recessed grip for detaching the cover of
the dust container compartment
5 Bumper
6 Round broom
7 AC adapter plug
8 AC adapter cord
9 AC adapter
10 Battery pack
 not shown: Operating manual
5
4
9
7
8
10
1
2
3
6
6
1
