7
Press latch on the front of
the dirt cup and pull out.
Hold dirt cup over trash can.
Pull filter up and out of dirt
cup. Gently tap the filter firm-
ly against the inside of a
trash can until dirt stops
falling from the filter.
Hold dirt cup over trash can
and shake out any remaining
dirt and debris.
FILTER/DIRT CUP REMOVAL/REPLACEMENT
1.
2.
3.
DIRT CUP REMOVAL
Gently push filter back into
dirt cup.
4.
Align bottom of dirt cup with
hole opening. Hold down the
button and gently push dirt
cup into place. You will feel it
lock into place.
5.
FILTER REPLACEMENT
DIRT CUP REPLACEMENT
WARNING: TO REDUCE THE RISK OF INJURY FROM MOVING PARTS - UNPLUG
BEFORE SERVICING.
GENERAL MAINTENANCE
To remove a clog in the nozzle:
Insert end of standard (flat head)
screwdriver into slot and pry noz-
zle access window out.
1.
Pull out obstruction. Return
the nozzle access window
back into its place.
2.
CLEAN NOZZLE CLOG
