Specifications
Electrical
Power consumption max. 150W/48V
Supply voltage for DC 5980
units
125W/48V
Sound quality
24 bit audio, 32 kHz sampling
frequency
Frequency response 65 Hz-16 kHz
THD < 0.1 %
Signal-to-noise ratio > 85 dBA
Audio inputs
Analog audio input
One 3-pin female XLR socket
(electronically balanced)
Analog audio in 2
(Emergency input - EEM
One 3-pin female XLR socket
(electronically balanced)
Audio outputs
Analog audio out
Four 3-pin male XLR sockets
(electronically balanced)
Maximum load > 1 k ohm
Interconnections
DCS-LAN Two RJ45 female sockets
EEM One contact closure input
System Performance
Max. number of discussion
units
250
Max. number of IS units 32
Max. number of languages 2
Max. number of open
"floor"microphones
8
Mechanical
Mounting
Tabletop or mounted in a 19",
one-unit rack
Color Black
Dimensions without feet (H
x W x D)
44.4 x 426 x 186 mm
Weight 2800 g
Storage temperature
-20° to 60° C, 10-80%
humidity
Optimal operating
temperature
5° to 40° C, 35-80% humidity
PS CU External Power Supply
Main voltage 100-240 V, 50-60 Hz
Max. consumption 175 W
Total supply power 150 W
Standby consumption <0.5 W
Supply voltage for CU 6110 48V/3A
Certifications
The DDS 5900 system in general conforms to the IEC 60914 standard,
however some functionalities, when the unit is configured as interpreter
unit, does not fulfill all requirements in the standard.
PS CU approvals CE, KC, CCC, cULus, TÜV
