Distech Controls LC-3 User Manual

10
object-name
object
-
type
object
-
instance description commandable
Inlet Temperature AI 1
Outside Temperature
Sensor Y
Inlet Humidity AI 2
Outside Humidity
Sensor Y
Cooling Coil Temperature AI 3 Coil Exit Temperature Y
Pre-Heat Exit Temperature AI 4
Preheat Exit
Temperature Sensor Y
Discharge Temperature 1 AI 5
Discharge Temperature
Sensor 1 Y
Discharge Humidity 1 AI 6
Discharge Humidity
Sensor 1 Y
Discharge Temperature 2 AI 7
Discharge Temperature
Sensor 2 Y
Discharge Humidity 2 AI 8
Discharge Humidity
Sensor 2 Y
Airflow Transmitter AI 9
Discharge Airflow
Transmitter Y
Fan ON BI 10 Fan Running Contact Y
Preheat Burner ON BI 11
Preheat
Burner ON
Contact Y
Preheat Burner Lockout BI 12
Preheat Burner Lockout
Contact Y
Unit Enable BO 1
Unit Enable
-
Open
Damper Y
Pre-Heat Enable BO 2 Preheat Enable Contact Y
Re-Heat Enable BO 3 Reheat Enable Contact Y
Preheat Burner Reset BO 4
Preheat Burner Reset
Contact Y
Reheat Burner Reset BO 5
Reheat Burner Reset
Contact Y
Cooling Enable BO 6 Cooling Enable Contact Y
Pre-Heat Command AO 7 Preheat Command Y
Re-Heat Command AO 8 Reheat Command Y
Cooling Command AO 9 Cooling Command Y
Humidity Enable BO 10
Humidity Enable
Contact Y
Humidity Command AO 11 Humidity Command Y
VFD Command AO 12 VFD Command Y
User HMI_SpaceTemp AI 5001 User HMI SpaceTemp N
CoolingCommandPID LOOP 1 Y
DirtyPreFitlerAlarm MSV 1
Dirty Filter Alarm [MSV
Enumerated] Y
LowTempAlarm MSV 2
Low Temp Alarm [MSV
Enumerated] Y
