Distech Controls LC-3 User Manual

11
DischargeSensorAlarm MSV 3
Discharge Temp Sensor
Alarm [MSV
Enumerated] Y
OutsideTempSensorAlarm MSV 5
Outside Temp Sensor
Alarm [MSV
Enumerated] Y
OutsideHumiditySensorAlarm MSV 6
Outside Humidity
Sensor Alarm [MSV
Enumerated] Y
PreheatBurnerLockoutAlarm MSV 7
Burner Lockout Alarm
[MSV Enumerated] Y
MotorNotRespondingAlarm MSV 9
Motor Not Responding
Alarm [MSV
Enumerated] (unit was
commanded on for 2
minutes and fan motor
did not start) Y
Reheat Burner ON BI 13
Reheat Burner ON
Contact Y
Reheat Burner Lockout BI 14
Reheat Burner Lockout
Contact Y
Dirty Pre-Filter Switch BI 15
Dirty Pre
-
Filter Switch
Contact Y
Dirty Final Filter Switch BI 16 Dirty Final Filter Contact Y
Humidity_PID LOOP 2 Humidity Control PID Y
PreHeat_PID LOOP 3 Preheat Control PID Y
ReHeat_PID LOOP 4 Reheat Control PID Y
Airflow PID LOOP 5 Airflow Control PID Y
LowTempAlarmSetPoint AV 1
Low Temp Alarm Set
Point Y
LowTempAlarmTime AV 2
Low Temp Alarm Time
(minutes) Y
MinimumDischargeTemp AV 3
Minimum Discharge
Temperature Y
MaximumDischargeTemp AV 4
Maximum Discharge
Temperature Y
DirtyPreFilterSwitchAvail BV 1
Dirty Pre
-
Filter Switch
Available Y
DirtyFinalFilterSwitchAvail BV 2
Dirty Final Filter Switch
Available Y
HumidificationAvailable BV 3 Humidification Available Y
HumidificationType BV 4
Humidification Type
(EVAP/STEAM) Y
ReHeatAvailable BV 5 Reheat Available Y
