1030/1230 - SPECIFICATIONS 63
1030
1030/1230 - SPECIFICATIONS 63
1030
POWER U.S. METRIC
Maximum governed speed installed (no load) 3400 rpm 3400 rpm
Flywheel power @ 3200 rpm (full load) 10.2 hp 7.5 kW
Fuel consumption @3600 rpm .89 gph 3.4 L/h
Maximum tilt angle 20° 20°
Fuel tank capacity 1.7 gal 6.5 L
Engine oil capacity 2.3 pt 1.1 L
POWER TRAIN
Ground drive transmission
Ground drive: hydrostatic, infinitely variable from zero to maximum,
gearbox to axle, speed and direction controlled with single lever
Pump drive clutch: mechanical, hand-operated, spring-loaded, with
tension roller for belt drive
Digging chain clutch: mechanical, hand-operated,spring-loaded with
tension roller for belt drive
Tires
Drive, standard: 16x6.50x8
Drive, optional: 18x8.50x8
Trail: 13x5.00x6
Trencher drive: mechanical, belt drive to reduction drive, headshaft
Belt: “power band,” two-groove
Digging chain: 33,000 lb (16 969 kg) test
Chain drive sprocket: forged and tempered
Digging teeth: bolt-on cup teeth with hard-surfaced edge of tungsten carbide
Spoils handling drive: mechanical, attached to and rotates with headshaft
NOISE LEVELS
Operator 88dBA sound pressure per ISO 6394.
Exterior 101 dBA sound power per ISO 6393.
VIBRATION LEVELS
Vibration at the operator’s hand during normal operation is 6.1 m/s
2
POWER U.S. METRIC
Maximum governed speed installed (no load) 3400 rpm 3400 rpm
Flywheel power @ 3200 rpm (full load) 10.2 hp 7.5 kW
Fuel consumption @3600 rpm .89 gph 3.4 L/h
Maximum tilt angle 20° 20°
Fuel tank capacity 1.7 gal 6.5 L
Engine oil capacity 2.3 pt 1.1 L
POWER TRAIN
Ground drive transmission
Ground drive: hydrostatic, infinitely variable from zero to maximum,
gearbox to axle, speed and direction controlled with single lever
Pump drive clutch: mechanical, hand-operated, spring-loaded, with
tension roller for belt drive
Digging chain clutch: mechanical, hand-operated,spring-loaded with
tension roller for belt drive
Tires
Drive, standard: 16x6.50x8
Drive, optional: 18x8.50x8
Trail: 13x5.00x6
Trencher drive: mechanical, belt drive to reduction drive, headshaft
Belt: “power band,” two-groove
Digging chain: 33,000 lb (16 969 kg) test
Chain drive sprocket: forged and tempered
Digging teeth: bolt-on cup teeth with hard-surfaced edge of tungsten carbide
Spoils handling drive: mechanical, attached to and rotates with headshaft
NOISE LEVELS
Operator 88dBA sound pressure per ISO 6394.
Exterior 101 dBA sound power per ISO 6393.
VIBRATION LEVELS
Vibration at the operator’s hand during normal operation is 6.1 m/s
2
