32 750/752 Tracker - OPERATION
BEACON TRACKING MODES
32 750/752 Tracker - OPERATION
BEACON TRACKING MODES
Pitch
Tracker shows pitch (% grade) when used with beacons that
provide this information (see specific beacon literature).
Pitch shows beacon grade in percentages from down arrow 99%
(45 degrees down) to up arrow 99% (45 degrees up). Tracker
displays this information to the left of roll display.
Grade beacons will send pitch in 0.1% increments from 1-45%
and in 1% increments from 45-90%.
% of
grade
Rise/drop
US (metric)
% of
grade
Rise/drop
US (metric)
% of
grade
Rise/drop
US (metric)
1 1” (25 mm) 12 1’ 2”
(356 mm)
45 4’ 1”
(1.24 m)
2 2” (51 mm) 14 1’ 5”
(432 mm)
50 4’ 6”
(1.37 m)
34”
(102 mm)
16 1’ 7”
(483 mm)
55 4’ 10”
(1.47 m)
45”
(127 mm)
18 1’ 9”
(533 mm)
60 5’ 2”
(1.57 m)
56”
(152 mm)
20 2’ (610 mm) 65 5’ 5”
(1.65 m)
67”
(178 mm)
24 2’ 4”
(711 mm)
70 5’ 9”
(1.75 m)
78”
(203 mm)
28 2’ 8”
(813 mm)
75 6’ (1.83 m)
810”
(254 mm)
32 3’ 1”
(940 mm)
80 6’ 3”
(1.91 m)
911”
(279 mm)
36 3’ 5”
(1.04 m)
90 6’ 8”
(2.03 m)
10 1’ (305 mm) 40 3’ 9”
(1.14 m)
99 7’ (2.13 m)
Pitch
Tracker shows pitch (% grade) when used with beacons that
provide this information (see specific beacon literature).
Pitch shows beacon grade in percentages from down arrow 99%
(45 degrees down) to up arrow 99% (45 degrees up). Tracker
displays this information to the left of roll display.
Grade beacons will send pitch in 0.1% increments from 1-45%
and in 1% increments from 45-90%.
% of
grade
Rise/drop
US (metric)
% of
grade
Rise/drop
US (metric)
% of
grade
Rise/drop
US (metric)
1 1” (25 mm) 12 1’ 2”
(356 mm)
45 4’ 1”
(1.24 m)
2 2” (51 mm) 14 1’ 5”
(432 mm)
50 4’ 6”
(1.37 m)
34”
(102 mm)
16 1’ 7”
(483 mm)
55 4’ 10”
(1.47 m)
45”
(127 mm)
18 1’ 9”
(533 mm)
60 5’ 2”
(1.57 m)
56”
(152 mm)
20 2’ (610 mm) 65 5’ 5”
(1.65 m)
67”
(178 mm)
24 2’ 4”
(711 mm)
70 5’ 9”
(1.75 m)
78”
(203 mm)
28 2’ 8”
(813 mm)
75 6’ (1.83 m)
8 10”
(254 mm)
32 3’ 1”
(940 mm)
80 6’ 3”
(1.91 m)
911”
(279 mm)
36 3’ 5”
(1.04 m)
90 6’ 8”
(2.03 m)
10 1’ (305 mm) 40 3’ 9”
(1.14 m)
99 7’ (2.13 m)
