21
GLOBE - IP1839
GB
Description OFF ON
DIP1 Control 1-5 function. Step by step. Opening.
DIP2 Selection of direction. Opening towards gearmotor. Closing towards gearmotor.
DIP3 Disengagement on
the closing
stop with JR2=ON
2 mm 0,5 mm
Note: use this selection to prevent an in-
complete closing of the sectional doors.
Disengagement
on
the closing
stop with JR2=OFF
5 mm
DIP4 State of door at start.
Indicates how
the electronic panel
considers the door at the time of
start.
Open.
With
DIP1=OFF the first control 1-5 closes
the door.
With DIP1=ON the first control 1-5 opens
the door.
Close.
The first control 1-5 opens the door
.
Note: automatic closing cannot be the first
control even if enabled.
DIP5 Electric lock release. Disabled. Enabled.
Before
opening
from closed door, a thrust
is included in closing to facilitate electric
lock release.
DIP6 Pre-flashing light. Disabled during opening.
Enabled
only
with automatic closure with
TC>3 s.
Enabled for both opening and closing.
5.4 Signals
LED ON Flashing
POWER ALARM 24 V= power supply. Encoder / automation fault.
SA Indicates that
at least one of the N.C. safety con-
tacts is open.
Upon starting
the LED flashes indicating the count
of the operations which have been carried out:
each quick flashing = 1000 operations
each slow flashing = 10000 operations
SIG During radio transmitter enabling/storing phase.
During radio transmission reception.
71R
5.2 Dip-Switches
Description OFF ON
SO Safety operation. Th
e opening of contact 1-8 with door
stopped enables opening manoeuvre. In
the last 30 mm before closing stop, this
causes stop.
T
he opening of contact 1-8 with door
stopped prevents any operation.
JR2 Automation type. Up and over door with counterweight. Se
ctional and up and over door with springs.
JR3 Maximum limit manoeuvering
forces.
Normal closing force.
Note: use safety edge.
Reduced closing force.
JR4
Built-in radio receiver. Disabled. Enabled.
5.3 Jumpers
