diversey TrailBlazer - Assembly; Parts Included

1
Assembly
Parts Included
Main Components
A. Body - (1)
B. Upper Handle - (1)
C. Bail - (1)
D. Hardware Assembly Packet - (1)
E. Lower Handle - (1)
F. Base Plate Support Bar - (1)
G. Base Plate - (1)
H. Base Plate Shaft - (1)
I. Base Plate Springs - (2)
Hardware Assembly Package
J. Lower mounting bracket - (1)
K. Upper mounting bracket - (1)
L. Lower mounting bracket bolt with star
washer M6-1.0x15mm - (1)
M. M6 locking nut - (1)
N. Washers - (4)
O. 16mm nuts - (5)
P. Upper mounting bracket bolt with star
washer M6-1.0x40mm - (1)
Q. Handle hinge screws - (2)
R. Lock washers - (4)
S. Hand tool - (1)
