SPECIFICATIONS
Power source AC 230V~50Hz / AC 120V~ 60Hz
Fuse T500mAL/250V / T1AL/125V (5x20mm)
Power consumption 0W/ 31 W (off/ max)
Input sensitivity:
Mic 1 40dB Gain, XLR electronically balanced and unbalanced input.
Mic 2 40dB Gain, XLR electronically balanced and unbalanced input.
Phono in 40dB Gain, unbalanced input.
Line in 0dB Gain, unbalanced input
Aux in 0dB Gain, unbalanced input
Return in 0dB Gain, unbalanced input
Input impedance:
Mic 1 34Kohm
Mic 2 34Kohm
Phono in 31Kohm
Line in 3.6Kohm
Aux in 3.6Kohm
Return in 31Kohm
Output voltage 6.2V RMS @ 10kohms (Main unbalanced output)
Output impedance 550 ohms (Main unbalanced output)
Frequency response 20Hz – 20kHz (+/-3dB)
THD Typ.＜0.07% (Output less than +18dBu)
Max.＜0.15% (Output less than +18dBu)
S/N ratio >77dB (Line)
Channel separation >65dB (Line)
Dimensions 483(H)x360(W)x110(D)mm
Weight 7.6kg
