dji AVATA 2 User Manual

DJI Avata 2 User Manual
©
2024 DJI All Rights Reserved.
17
1
2
+2.0D ~ -6.0D +2.0D ~ -6.0D
• After installing the -2.0D Corrective Lenses, the diopter value displayed on the screen
is not the actual diopter value. The actual diopter value is the sum of the on-screen
value and -2.0D.
2. Take out the -2.0D Corrective Lenses and peel o the protective lm. Distinguish the left and
right lenses via the L and R marks on the bottom.
3. Align the positioning marks on the left and right sides of the corrective lens frame with the
marks on the inner circle of the goggle lens frame. Mount the corrective lens by pressing it
down, and then rotate it clockwise until the marks on the corrective lens frame are aligned
with the marks on the goggle lens frame.
4. Adjust the diopters of the goggles according to your needs and lock the knobs.
L
1
2
R
0D ~ -8.0D0D ~ -8.0D
1. Detach the original lens frames from the goggles by rotating counterclockwise as shown.

dji AVATA 2 Specifications

General

Type	Quadcopter
Product color	Black
Construction type	Ready-to-fly (RTF)
Suitable for outdoor use	Yes
Maximum speed	27 m/s
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Number of rotors	4 rotors
Bluetooth version	5.0
Maximum flight time	23 min
Maximum flight altitude	5000 m
Maximum weight capacity	- kg
Maximum wind resistance	10.7 m/s
Horizontal hover accuracy	0.3 m
Maximum operating distance	13000 m
Megapixel	12 MP
Video color modes	D-Log, Normal
Video resolutions	1440 x 1080, 1920 x 1080, 2688 x 1512, 2688 x 2016, 3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/1.3 \
Camera shutter speed	Video: 1/8000-1/30, Photo: 1/8000-1/50 s
Mechanical tilt range	-95 - 90 °
Normal focusing range	0.6 - ∞ m
Supported file systems	exFAT
Angular vibration range	-0.01 - 0.01 °
Image formats supported	JPEG
Maximum aperture number	2.8
Video formats supported	H.264, H.265, MP4
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2880 pixels
Field of view (FOV) angle	155 °
Bitrate at maximum video resolution	130 Mbit/s
Built-in processor	-
Internal memory	46 GB
Operating frequency	2400 - 2483.5 MHz
Battery voltage	14.76 V
Battery capacity	2150 mAh
Antennas quantity	4
Operating temperature (T-T)	-10 - 40 °C
Equivalent Isotropically Radiated Power (EIRP)	10 dBmW
Package type	Box
Cables included	USB Type-C

Weight and Dimensions

Depth	212 mm
Width	185 mm
Height	64 mm
Weight	377 g
