dji AVATA 2 User Manual

DJI Avata 2 User Manual
28
©
2024 DJI All Rights Reserved.
Unlocking GEO Zones
To satisfy the needs of dierent users, DJI provides two unlocking modes: Self-Unlocking and
Custom Unlocking. Users may make a request on the DJI Fly Safe website.
Self-Unlocking is intended for unlocking Authorization Zones. To complete Self-Unlocking, the user
must submit an unlocking request via the DJI Fly Safe website at https://y-safe.dji.com. Once the
unlocking request is approved, the user may synchronize the unlocking license through the DJI
Fly app. Alternatively, to unlock a zone, the user may launch or y the aircraft directly into the
approved Authorization Zone and follow the prompts in DJI Fly to unlock the zone.
Custom Unlocking is tailored for users with special requirements. It designates user-defined
custom ight areas and provides ight permission documents specic to the needs of dierent
users. This unlocking option is available in all countries and regions and can be requested via
the DJI Fly Safe website at https://www.dji.com/ysafe.
• To ensure flight safety, the aircraft will not be able to fly out of the unlocked zone after
entering it. If the Home Point is outside the unlocked zone, the aircraft will not be able to
return home.

dji AVATA 2 Specifications

General

Type	Quadcopter
Product color	Black
Construction type	Ready-to-fly (RTF)
Suitable for outdoor use	Yes
Maximum speed	27 m/s
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Number of rotors	4 rotors
Bluetooth version	5.0
Maximum flight time	23 min
Maximum flight altitude	5000 m
Maximum weight capacity	- kg
Maximum wind resistance	10.7 m/s
Horizontal hover accuracy	0.3 m
Maximum operating distance	13000 m
Megapixel	12 MP
Video color modes	D-Log, Normal
Video resolutions	1440 x 1080, 1920 x 1080, 2688 x 1512, 2688 x 2016, 3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/1.3 \
Camera shutter speed	Video: 1/8000-1/30, Photo: 1/8000-1/50 s
Mechanical tilt range	-95 - 90 °
Normal focusing range	0.6 - ∞ m
Supported file systems	exFAT
Angular vibration range	-0.01 - 0.01 °
Image formats supported	JPEG
Maximum aperture number	2.8
Video formats supported	H.264, H.265, MP4
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2880 pixels
Field of view (FOV) angle	155 °
Bitrate at maximum video resolution	130 Mbit/s
Built-in processor	-
Internal memory	46 GB
Operating frequency	2400 - 2483.5 MHz
Battery voltage	14.76 V
Battery capacity	2150 mAh
Antennas quantity	4
Operating temperature (T-T)	-10 - 40 °C
Equivalent Isotropically Radiated Power (EIRP)	10 dBmW
Package type	Box
Cables included	USB Type-C

Weight and Dimensions

Depth	212 mm
Width	185 mm
Height	64 mm
Weight	377 g
