dji AVATA 2 User Manual

DJI Avata 2 User Manual
34
©
2024 DJI All Rights Reserved.
When the accelerator is not pressed, the aircraft will hover.
1
When gently pressing the accelerator to the rst stop, you
can adjust the aircraft orientation by tilting the motion
controller vertically to the left or right.
Note that the aircraft will not y forward at this time.
2
Press the accelerator to the second stop to make the
aircraft to y in the direction of the circle in the goggles.
Taking O, Braking and Landing
Takeo
Press the lock button twice to start the aircraft motors, then press and hold
the button again to make the aircraft take off. The aircraft will ascend to
approximately 1.2 m and hover.
Braking
Press the lock button during ight to make the aircraft brake and hover in place.
Press again to resume ight control.
Landing
Press and hold the lock button while the aircraft is hovering to land it
automatically and stop the motors.
• After the aircraft motors have been started by double-pressing the lock button, slowly
push the joystick up to make the aircraft take o.
• When Easy ACRO is disabled, once the aircraft ies to the landing position, gently push
the joystick downwards to land the aircraft. After landing, push the joystick down and
hold in position until the motors stop.

dji AVATA 2 Specifications

General

Type	Quadcopter
Product color	Black
Construction type	Ready-to-fly (RTF)
Suitable for outdoor use	Yes
Maximum speed	27 m/s
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Number of rotors	4 rotors
Bluetooth version	5.0
Maximum flight time	23 min
Maximum flight altitude	5000 m
Maximum weight capacity	- kg
Maximum wind resistance	10.7 m/s
Horizontal hover accuracy	0.3 m
Maximum operating distance	13000 m
Megapixel	12 MP
Video color modes	D-Log, Normal
Video resolutions	1440 x 1080, 1920 x 1080, 2688 x 1512, 2688 x 2016, 3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/1.3 \
Camera shutter speed	Video: 1/8000-1/30, Photo: 1/8000-1/50 s
Mechanical tilt range	-95 - 90 °
Normal focusing range	0.6 - ∞ m
Supported file systems	exFAT
Angular vibration range	-0.01 - 0.01 °
Image formats supported	JPEG
Maximum aperture number	2.8
Video formats supported	H.264, H.265, MP4
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2880 pixels
Field of view (FOV) angle	155 °
Bitrate at maximum video resolution	130 Mbit/s
Built-in processor	-
Internal memory	46 GB
Operating frequency	2400 - 2483.5 MHz
Battery voltage	14.76 V
Battery capacity	2150 mAh
Antennas quantity	4
Operating temperature (T-T)	-10 - 40 °C
Equivalent Isotropically Radiated Power (EIRP)	10 dBmW
Package type	Box
Cables included	USB Type-C

Weight and Dimensions

Depth	212 mm
Width	185 mm
Height	64 mm
Weight	377 g
