5
Connecting the Antennas (Figure B)
The dongle uses TS-5 antenna ports. Use antenna cables with TS-5 connectors for
connection.
Connect the antenna cables to the antenna ports of the dongle and firmly secure the
cables.
• Make sure that both antenna cables are rmly connected and the cable
routing is tidy to avoid squeezing the wires. Otherwise, it may aect the
transmission performance or the use of related functions.
• The cable clip should be mounted to secure the antenna cables when using
certain devices. Refer to the relevant document of the corresponding device
for more information.
Connecting to a Device
The dongle can connect to a computer or compatible DJI devices. Connect the USB-C
port on the dongle to the corresponding port on a device using a compatible cable
according to the port.
Status Indicator Descriptions
The dongle will automatically power on when the connected device is powered on.
The status indicator indicates the current working status. Refer to the table below for
more information.
Blinking Pattern Description
Solid red During startup or no nano-SIM card detected after startup.
Solid green Strong 4G signal in use.
Blinks green slowly Weak 4G signal in use.
Blinks green quickly
4G connection not established. Wait for establishment/restart
the device/move the device to a location with strong signal.
Solid blue Strong 3G signal in use.
Blinks blue slowly Weak 3G signal in use.
