6
Blinks blue quickly
3G connection not established. Wait for establishment/restart
the device/move the device to a location with strong signal.
Blinks red No network signal.
Specifications
Telecommunication
Standards
TDD-LTE/FDD-LTE/WCDMA
Operating
Frequency Bands
TDD-LTE: B34/38/39/40/41(194M)
FDD-LTE: B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/B19/B20/B25/
B26/B28/B66/B71
WCDMA: B1/B2/B4/B5/B6/B8/B19
Interface USB-C port, nano-SIM card slot, TS-5 antenna ports
Antennas Dual antennas
Dimensions 43.5×23.0×7.0 mm
Weight Approx. 11.5 g
Operating Voltage/
Current
5 V, 1 A
Operating
Temperature
-30° to 65° C (-22° to 149° F)
Storage
Temperature
-40° to 85° C (-40° to 185° F)
