6
Lens Conáguration
Lens configuration can be used to store up to three sets of calibrated lens parameters.
Once stored, users can select parameters directly by tapping Lens Configuration.
Usage
If the camera lens is replaced, the focus motor must be recalibrated the next time the
3D Focus System is powered on. To calibrate the focus motor, either double tap the
AF/MF Switch button or follow the prompts to calibrate the focus motor after selecting
the lens in Lens Configuration.
To switch between AF and MF, press the AF/MF Switch button once or switch between
AF and MF on the touchscreen. Once in AF, the 3D Focus System will be active and
the status indicator turns solid green.
DO NOT hot plug and unplug the 3D Focus System. Otherwise, the
parameters will be lost and the focus motor will need to be calibrated again.
Only manual focus lenses with a mechanical limit are supported.
DO NOT use corrosive organic solvents such as alcohol to wipe the lens of
the 3D Focus System.
Make sure the infrared distance sensor (TOF) is not blocked by the hood
or filter of the camera. Otherwise, the auto focus of the 3D Focus will be
inaccurate.
Status Indicator Description
Status Indicator Description
Solid green The 3D Focus System is working in AF
Solid yellow The 3D Focus System is calibrated and working in MF
Solid red The 3D Focus System needs calibrating
Specications
Model DF01
Weight 54.8 g
