DJI OcuSync Air System

Weight Air Unit: 43.7 g; Camera (cable included): 18.2 g

Pagoda Antenna: 9.4 g; Cylindrical Antenna: 9.4 g;

Dipole Antenna: 4.2 g

Dimensions Air Unit: 72 × 33 × 14 mm

Camera: 29.4 × 28.2 × 22.6 mm

Communication Frequency 2.4 GHz / 5.8 GHz

Transmitter Power (EIRP) 2.4 GHz: 22.5 dBm (FCC); 18.5 dBm (CE); 19 dBm (SRRC)

5.8 GHz: 25.5 dBm (FCC); 12.5 dBm (CE); 25.5 dBm (SRRC)

Live View Modes and Min. Latency 960p50: 70 ms; 720p60: 60 ms; 480p50: 50 ms

Max. Transmission Distance 2.4 GHz: 7 km (FCC); 4 km (CE); 4 km (SRRC)

5.8 GHz: 4 km (FCC); 0.7 km (CE); 4 km (SRRC)

Recommended Frequency Band FCC: 5.8 GHz; CE: 2.4 GHz; SRRC: 5.8 GHz

Video Format MP4 (MPEG4)

I/O Interface S.Bus, Micro USB, PPM, UART, MMCX, Micro SD card slot

Supported Flight Control System F3, F4, KISS, NAZE

Supported Remote Controller X9D (Frsky), DEVO 10 (Walkera), T8FG (Futaba),

T14SG (Futaba), WTF09sll (WFLY), AT9S (RadioLink)

Operating Temperature Range 32° to 104° F (0° to 40° C)

Input Power 9-16.8 V (3S-4S)

Camera Sensor: 1/3'' CMOS; Effective pixels: 1.2M

Lens: 2.65 mm, f/2.0

Lens Group: 6G + IR

Shutter: Global shutter

ISO: 100 - 3200

FOV: 148° (D); 111° (H); 79.5° (V)
