dji Goggles RE User Manual

EN
10
Controls
Single Finger Touch /
5D Button*
●
Swipe to scroll on the menu
●
Tap to conrm
Two Fingers Touch
●
Swipe forward/backward to unlock/
lock the touch panel
●
Swipe upward/downward to exit/enter
the shortcut menu
Only supports:
Mavic Series
Spark
Phantom 4 Series
Inspire 2
Somatic Control
DJI Goggles RE
support head tracking,
allowing aircraft
and gimbal to be
controlled using head
movements. Multi
Intelligent Flight Modes
are also supported.
Function Button / C1 Button*
DJI aircraft: Press to display the cursor,
then swipe forward/backward with one
nger to zoom in or zoom out. Move your
head then tap the touch panel to dene the
focus point.
Other aircraft: Press to start/stop video
recording (digital video transmission only).
Back Button / C2 Button*
Press to return to the previous
menu, or exit the current
Intelligent Flight Mode.
* When connected to Mavic series aircraft, the 5D, C1, and C2 buttons on the remote
controller will be used to control the DJI Goggles RE, and their original functions will
be disabled.
Fn
Specications
DJI Goggles RE
Weight (Typical) DJI Goggles RE Body: 502 g; Headband: 500 g
Dimensions DJI Goggles RE Body: 195 × 155 × 110 mm
Headband (folded): 255 × 205 × 92 mm
Screen Size 5-inch × 2
Screen Resolution 3840 × 1080 (single screen: 1920 × 1080)
Communication Frequency 2.4 GHz / 5.8 GHz
Transmitter Power (EIRP) 2.4 GHz: 25.5 dBm (FCC); 18.5 dBm (CE); 19 dBm (SRRC)
5.8 GHz: 25.5 dBm (FCC); 12.5 dBm (CE); 18.5 dBm (SRRC)
Live View Modes 1080p30, 720p60, 720p30
Video Format MP4 (H.264)
Supported Video Play Format MP4, MOV, MKV (Video format: H264;
Audio format: AAC-LC, AAC-HE, AC-3, DTS, MP3)
Battery Capacity 9440 mAh
Operating Temperature Range 32° to 104° F (0° to 40° C)
Charger Input: 100-240 VAC, 50 / 60 Hz, 0.5 A
Output: 5 V
3 A / 9V 2A / 12 V 1.5 A
