2017 DJI All Rights Reserved.
11
3
4
6. Installation is complete.
• DO NOT let the cable pass through
the middle of the antennas, or it may
negatively affect the signal.
• The side marked with the DJI logo should
face out when the master part is properly
mounted.
• DO NOT cover the GPS Module with
metal.
• Ensure the cable is inserted correctly or the
CAN Bus port may be damaged.
• Always power off the remote controller
when mounting the GPS Module.
• Press hard when mounting the Master
part of the GPS module and the Can
Hub, or the Velcro may not be able to
tighten the GPS Module securely.
