dji Matrice 200 Series V2 User Manual

4
EN
Using Matrice 210 V2/Matrice 210 RTK V2
1. Downloading the DJI Pilot App
Users can access the DJI Pilot app that is built-in to the remote controller’s CrystalSky monitor.
Users can also search for DJI Pilot in Google Play Store or scan the QR code to download the
app onto your mobile device, and then connect the mobile device to the remote controller.
First-time activation requires your DJI account and an internet connection.
Internet
DJI Pilot supports Android 5.0 or later.
2. Charging the Batteries
Press the release button and open the corresponding charging port cover.
Insert the Intelligent Flight Battery into the charging port to begin charging.
Be sure to press the release button when removing fully charged batteries.
When charging is complete, the LED lights on the Intelligent Flight Battery will turn off, and the LED on the Charging Hub will turn solid green.
When charging is complete, the display on the remote controller will show 100%.
The Charging Hub will sound an alert when the battery has been fully charged. The alert can be turned on or off by toggling the switch under the hub.
Install the battery into the aircraft and power on. If a low battery temperature is detected, the battery will automatically heat up to maintain a temperature between
16° and 20° C.
Ensure two Intelligent Flight Batteries are charged and discharged simultaneously to prolong their service life and for a better ight experience.
Using the IN2CH Charging Hub, charging time
is approximately
TB55: 2 hours and 24 min (two batteries)*
Charging Time:
2 hours*
Using the WCH2 Charging Hub,
charging time is approximately
1 hour and 11 min (one battery)*
* Provided charger.
The battery must be fully charged before
using it for the rst time.
Ensure that Part B is
unlocked. Connect Part
B to Part A.
Lock the Mounting
Bracket.
Use a coin or the screwdriver
included to adjust the
tightness of the tilt axis.
Mounting the Monitor to the Remote Controller
Press the Battery Release Button before removing the battery.
Press the Battery Level Button once to check the battery level.
3. Preparing the Remote Controller
CrystalSky monitors and the Cendence S remote controller
use the same batteries.
Put the battery into the Battery Slot, then slide it to the end
until you hear a click.
Mounting Monitor and Remote Controller Batteries
Low
High
DJI Pilot App
Power Outlet
100~240 V
(50Hz/60Hz)
A
2
1
A
B
B
B
A
B
