dji MAVIC 3E Quick Start Guide

Remote Controller
The DJI RC Pro Enterprise remote controller features O3 Enterprise, the latest version of DJI’s
signature OCUSYNC
TM
image transmission technology, and can transmit a live HD view from the
camera of an aircraft at a distance of up to 15 km*. The remote controller comes with a wide range of
aircraft and gimbal controls as well as customizable buttons. The built-in microphone allows recording
voice and 5.5-in high brightness 1000 cd/m
2
screen boasts a resolution of 1920×1080 pixels. Users
can connect to the internet via Wi-Fi and the Android operating system comes with a variety of
functions such as Bluetooth and GNSS.
1. Control Sticks
2. Back/Function Button
3. RTH Button
4. Flight Pause Button
5. Flight Mode Switch
6. 5D Button
7. Power Button
8. Confirm Button/Customizable C3
Button
9. Touchscreen
10. M4 Screw Hole
11. microSD Card Slot
12. USB-C Port
13. Mini HDMI Port
14. Microphone
15. Gimbal Dial
16. Record Button
17. Antennas
18. Status LED
19. Battery Level LEDs
20. Focus/Shutter Button
21. Camera Settings Dial
22. Air Vent
23. Control Sticks Storage Slot
24. Customizable C1 Button
25. Speaker
26. Customizable C2 Button
27. Air Intake
* The remote controller is able to reach its maximum transmission distance (FCC) in a wide-open area
with no electromagnetic interference at an altitude of about 400 ft (120 m).

dji MAVIC 3E Specifications

General

Effective Pixels	20 MP
Max Flight Time	46 minutes
Max Transmission Range	15 km
Max Wind Resistance	12 m/s
Aircraft Type	Quadcopter
Max Takeoff Weight	920 g
Diagonal Distance	380.1 mm
Max Ascent Speed	8 m/s
Max Descent Speed	6 m/s
Max Horizontal Speed	21 m/s
Max Flight Distance	32 km
Max Tilt Angle	35°
GNSS	GPS+Galileo+BeiDou
Internal Storage	8 GB
Max Speed	21 m/s
Gimbal	3-axis (tilt, roll, pan)
Battery Capacity	5000 mAh
Camera Sensor	4/3 CMOS
Obstacle Sensing	Omnidirectional
Dimensions (Folded without propellers)	221×96.3×90.3 mm
Dimensions (Unfolded without propellers)	347.5×283×107.7 mm
Operating Temperature	-10° to 40° C
Hovering Accuracy Range	Vertical: ±0.1 m (with vision positioning); ±0.5 m (with GNSS positioning), Horizontal: ±0.3 m (with vision positioning)
Storage Temperature	-20° to 45° C
Camera - Zoom	Yes, Hybrid Zoom
Charging Time	96 minutes
