dji MAVIC 3E Quick Start Guide

Mavic 3T Wide Camera
Sensor
1/2" CMOS; Effective pixels: 48M
Lens
FOV: 84°
Format Equivalent: 24 mm
Aperture: f/2.8
Focus 1 m to ∞
Mavic 3T Thermal Camera
Thermal Imager
Uncooled VOx Microbolometer
Lens
DFOV: 61°
Focal Length: 9.1 mm (equivalent: 40 mm)
Aperture: f/1.0
Focus: 5 m to ∞
Infrared Temperature
Measurement Accuracy
±2° C or ±2% (using the larger value)
Intelligent Flight Battery
Capacity
5000 mAh
Standard Voltage
15.4 V
Max Charging Voltage
17.6 V
Battery Type
LiPo 4S
Energy
77 Wh
Weight
335.5 g
Charging Temperature
5° to 40° C (41° to 104° F)
Battery Charger
Input
100-240 V AC, 50-60 Hz, 2.5 A
Output
Max. 100W (Total)
When both the ports are used, the maximum output power of each
interface is 82 W, and the charger will dynamically allocate the
output power of the two ports according to the load power.
Remote Controller (Model: RC510B)
Weight
Approx. 680 g
Battery
Li-ion (5000 mAh @ 7.2 V)
Storage Capacity
ROM 64GB + expandable storage via microSD card
Operating Time
3 hours
Operating Temperature
-10° to 40° C (14° to 104° F)
Charging Temperature
5° to 40° C (41° to 104° F)
GNSS
GPS + Galileo + GLONASS
O3 Enterprise
Operating Frequency
2.400-2.4835 GHz, 5.725-5.850 GHz
*
Max Transmission Distance
(Unobstructed, free of
interference)
15 km (FCC), 8 km (CE/SRRC/MIC)
Max Transmission Distance
Strong Interference (urban landscape, limited line of sight, many

dji MAVIC 3E Specifications

General

Effective Pixels	20 MP
Max Flight Time	46 minutes
Max Transmission Range	15 km
Max Wind Resistance	12 m/s
Aircraft Type	Quadcopter
Max Takeoff Weight	920 g
Diagonal Distance	380.1 mm
Max Ascent Speed	8 m/s
Max Descent Speed	6 m/s
Max Horizontal Speed	21 m/s
Max Flight Distance	32 km
Max Tilt Angle	35°
GNSS	GPS+Galileo+BeiDou
Internal Storage	8 GB
Max Speed	21 m/s
Gimbal	3-axis (tilt, roll, pan)
Battery Capacity	5000 mAh
Camera Sensor	4/3 CMOS
Obstacle Sensing	Omnidirectional
Dimensions (Folded without propellers)	221×96.3×90.3 mm
Dimensions (Unfolded without propellers)	347.5×283×107.7 mm
Operating Temperature	-10° to 40° C
Hovering Accuracy Range	Vertical: ±0.1 m (with vision positioning); ±0.5 m (with GNSS positioning), Horizontal: ±0.3 m (with vision positioning)
Storage Temperature	-20° to 45° C
Camera - Zoom	Yes, Hybrid Zoom
Charging Time	96 minutes
