dji OSMO MOBILE 3 Quick Start Guide

The Android version of DJI Mimo is compatible with Android v6.0 and later. The iOS version of DJI
Mimo is compatible with iOS v10.0 and later.
2. Powering On/Off/Charging
• When Osmo Mobile 3 is powered off, press the button to check battery level, press and hold
to power on/off.
• To charge the Osmo Mobile 3, connect the USB adapter (not included) to the charging port
using the provided power cable. The battery is fully charged when the Battery Level Indicators
turn solid on.
• USB Adapter Charging Time: 3.5 hours (when charging at 2 A) Max Run-Time: 15 hours*
• The Osmo Mobile 3’s USB-A port is capable of charging mobile phones. Connect the USB port
to your mobile phone using a standard Micro USB cable to start charging when the Osmo
Mobile 3 is powered on. Press the M button once to start charging when the Osmo Mobile 3
is powered off.
* Max run-time was tested with the gimbal balanced and held steadily. This value should be taken
for reference only.

dji OSMO MOBILE 3 Specifications

General

Type	Smartphone camera stabilizer
Material	-
Functions	Panorama, Timelapse, Slow Motion, Sport Mode
Motorized	Yes
Product color	Gray
Number of axis	3
Maximum device depth	9.5 mm
Maximum device width	88 mm
Minimum device width	62 mm
Maximum weight capacity	0.23 kg
Charging time	2.5 h
Operating time	15 h
Battery voltage	7.2 V
Battery capacity	2450 mAh
Operating temperature (T-T)	0 - 40 °C
Mechanical pan range	-162.5 - 170.3 °
Mechanical roll range	85.1 - 252.2 °
Mechanical tilt range	104.5 - 235.7 °
Bluetooth version	5.0
Cables included	USB

Weight and Dimensions

Depth	103 mm
Width	125 mm
Height	285 mm
Weight	405 g
Dimensions folded (WxDxH)	130 x 46 x 157 mm
