dji Phantom 3 Standard User Manual

8
©
20 5 DJ All Rights Reserved
Produc Prof e
Phantom 3 Standard Use Manua
Aircraft Diagram
Remote Controller Di gram
[1] Prope ers
[2] Mo ors
[3] Fron ED nd ca or
[4] A rcraf M cro USB Por
[5] Camera S a us nd ca or
[6] and ng Gear
[7] n e gen F g Ba ery
[8] G mba a d Camera
[9] A ennas
10] Camera M cro SD card s o
[11] nk Bu on
[12] Camera M cro USB Por
[13] A rcraf S a us nd ca or
[1] An enna
[2] Mob e Dev ce o der
[3] Sw ch S1
[4] Con ro S cks
[5] anyard oop
[6] Ba ery eve nd ca or
[7] S a us ED
[8] M cro USB Charg ng Por
[9] Power Sw ch
[10] G mba D a
[11] Sw ch S2
[12] and e Bar
[2]
[1]
[3]
[4]
[5]
[6]
[7]
[8]
[10]
[9]
[1 ]
[12]
[13]
[1]
[2]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
11]
[12]
[3]
www.carlosmendoza.com.mx

dji Phantom 3 Standard Specifications

General

Live view	Yes
Megapixel	12 MP
Video resolutions	1280 x 720, 1920 x 1080, 2704 x 1520 pixels
Maximum frame rate	60 fps
Camera shutter speed	8 - 1/8000 s
Supported video modes	1520p, 720p, 1080p
Video formats supported	AVC, H.264, MOV, MP4, MPEG4
Live view frequency band	2.4 GHz
Maximum video resolution	2704 x 1520 pixels
Field of view (FOV) angle	94 °
Bitrate at maximum video resolution	40 Mbit/s
Maximum speed	16 m/s
Frequency band	2.400 - 2.483 GHz
Number of rotors	4 rotors
Maximum flight time	23 min
Maximum descent speed	3 m/s
Maximum weight capacity	- kg
Maximum operating distance	1000 m
Battery voltage	15.2 V
Battery capacity	4480 mAh
Transmitter battery capacity	2600 mAh
Number of batteries (transmitter)	1
Certification	FCC, CE
Product color	Red, White
Flight modes	Failsafe mode
Moving control functions	Backward, Downward, Flying sideways, Forward, Turn left, Turn right, Upward
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	64 GB
Operating temperature (T-T)	0 - 40 °C
Motor type	Brushless
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
Power consumption (transmitter) (max)	600 mA

Weight and Dimensions

Weight	1216 g
Weight (including battery)	365 g
