Aircraft

Phantom 4 Advanced / Advanced+ User Manual

ON OFF

Auto Hold

• Landing Protection will not be active in the following circumstances:

a) When the user is controlling the pitch/roll/throttle sticks (Landing ground detection will

re-activate when control sticks are not in use)

b) When the positioning system is not fully functional (e.g. drift position error)

c) When the downward vision system needs re-calibration

d) When light conditions are not sufcient for the downward vision system

• If an obstacle is within 1-meter of the aircraft, the aircraft will descend to 0.3m above the

ground and hover. The aircraft will land upon with user conrmation.

Intelligent Flight Mode

TapFly

Introduction

With the TapFly feature, users can now tap on the mobile device screen to y in the designated direction

without using the remote controller. The aircraft will automatically avoid obstacles it sees or brake and hover

provided that the lighting is appropriate (< 300 lux) nor too bright (> 10,000 lux).

Using TapFly

Ensure the aircraft is in P-mode, then follow the steps below to use TapFly:

1. Take off and ensure the aircraft is ying at least 6 feet (2 meters) above the ground.

2 meters

2. Launch the DJI GO 4 app and tap

, then tap

, read and understand the prompts.

09:29

61%

P-GPS

H 10.0MD 30M

VS 2.0M/S VPS 2.0MH.S 10.0 M/S

In Flight (GPS)

Questions and Answers:

Need help?

Do you have a question about the dji PHANTOM 4 ADVANCED and is the answer not in the manual?

dji PHANTOM 4 ADVANCED Specifications

General

Camera Sensor	1-inch CMOS
Effective Pixels	20 MP
Max Flight Time	30 minutes
Weight	1388 g
Max Ascent Speed	6 m/s (Sport mode)
Max Descent Speed	4 m/s (Sport mode)
GPS Mode	GPS/GLONASS
Video Storage Bitrate	100 Mbps
Photo Format	JPEG, DNG (RAW)
Battery Capacity	5870 mAh
Battery Voltage	15.2 V
Battery Type	LiPo 4S
Battery Energy	89.2 Wh
Gimbal	3-axis (pitch, roll, yaw)
Max Speed	72 kph (Sport mode)
Transmission Range	7 km
Operating Temperature Range	0° to 40°C (32° to 104°F)
Lens	24mm f/2.8
Supported File Systems	FAT32/exFAT
Video Format	MP4/MOV (H.264/MPEG-4 AVC)
Remote Controller Operating Frequency	2.400 GHz to 2.483 GHz, 5.725 GHz to 5.825 GHz
Remote Controller Max Transmission Distance	7 km
Video Resolution	4K 60fps
