dji PHANTOM 4 ADVANCED User Manual

Aircraft
22
©
2017 DJI All Rights Reserved.
Phantom 4 Advanced / Advanced+ User Manual
ON OFF
Auto Hold
2. Launch the DJI GO 4 app and tap , then tap , read and understand the prompts.
3.
Tap on the subject you want to track then tap to conrm selection. If the subject is not automatically
recognized, drag a box around it. The box
will turn green when tracking is in progress. If the box
turns red, the object could not be identied and you should try again.
2 meters
Using ActiveTrack
Ensure the aircraft is in P-mode, then follow the steps below to use ActiveTrack:
1. Take off and hover at least 6 feet (2 meters) above the ground.
AE
09:29
61%
P-GPS
12
H 10.0MD 30M
VS 2.0M/S VPS 2.0MH.S 10.0 M/S
In Flight (GPS)
AE
09:29
61%
P-GPS
12
H 10.0MD 30M
VS 2.0M/S VPS 2. 0MH.S 10.0 M/S
智能跟随
In Flight (GPS)

dji PHANTOM 4 ADVANCED Specifications

General

Camera Sensor	1-inch CMOS
Effective Pixels	20 MP
Max Flight Time	30 minutes
Weight	1388 g
Max Ascent Speed	6 m/s (Sport mode)
Max Descent Speed	4 m/s (Sport mode)
GPS Mode	GPS/GLONASS
Video Storage Bitrate	100 Mbps
Photo Format	JPEG, DNG (RAW)
Battery Capacity	5870 mAh
Battery Voltage	15.2 V
Battery Type	LiPo 4S
Battery Energy	89.2 Wh
Gimbal	3-axis (pitch, roll, yaw)
Max Speed	72 kph (Sport mode)
Transmission Range	7 km
Operating Temperature Range	0° to 40°C (32° to 104°F)
Lens	24mm f/2.8
Supported File Systems	FAT32/exFAT
Video Format	MP4/MOV (H.264/MPEG-4 AVC)
Remote Controller Operating Frequency	2.400 GHz to 2.483 GHz, 5.725 GHz to 5.825 GHz
Remote Controller Max Transmission Distance	7 km
Video Resolution	4K 60fps
