dji PHANTOM 4 ADVANCED User Manual

Aircraft
24
©
2017 DJI All Rights Reserved.
Phantom 4 Advanced / Advanced+ User Manual
ON OFF
Auto Hold
Exiting ActiveTrack
Use the following methods to exit ActiveTrack:
1. Tap the “STOP” button on the screen.
2. Press the Intelligent Flight Pause button on the remote controller.
After exiting ActiveTrack, the aircraft will hover in place, at which point you may choose to fly
manually, track another subject, or return to home.
OR
STOP
Draw
Introduction
Using Draw, the aircraft will y along the ight path drawn on-screen. As it ies it will automatically
brake and hover when it sees obstacles provided that the lighting is appropriate - no darker than
300 lux nor brighter than 10,000 lux.
Using Draw
Ensure the aircraft is in P-mode, then follow the steps below to use Draw:
1. Take off and hover at least 6 feet (2 meters) above the ground.
AE
09:29
61%
In Flight（GPS）
P-GPS
12
H 10.0MD 30M
VS 2.0M/S VPS 2. 0MH.S 10.0 M/S
3. Draw a line on the screen to create a path. Tap and the aircraft will y along the path.
2 meters
2. Launch the DJI GO 4 app and tap , then tap , read and understand the prompts.

dji PHANTOM 4 ADVANCED Specifications

General

Camera Sensor	1-inch CMOS
Effective Pixels	20 MP
Max Flight Time	30 minutes
Weight	1388 g
Max Ascent Speed	6 m/s (Sport mode)
Max Descent Speed	4 m/s (Sport mode)
GPS Mode	GPS/GLONASS
Video Storage Bitrate	100 Mbps
Photo Format	JPEG, DNG (RAW)
Battery Capacity	5870 mAh
Battery Voltage	15.2 V
Battery Type	LiPo 4S
Battery Energy	89.2 Wh
Gimbal	3-axis (pitch, roll, yaw)
Max Speed	72 kph (Sport mode)
Transmission Range	7 km
Operating Temperature Range	0° to 40°C (32° to 104°F)
Lens	24mm f/2.8
Supported File Systems	FAT32/exFAT
Video Format	MP4/MOV (H.264/MPEG-4 AVC)
Remote Controller Operating Frequency	2.400 GHz to 2.483 GHz, 5.725 GHz to 5.825 GHz
Remote Controller Max Transmission Distance	7 km
Video Resolution	4K 60fps
