dji PHANTOM 4 Flight Manual

Flight Procedure
1. Plan a mission on the Aerobotics Mission Planner app.
2. Choose an appropriate place to takeoff and land. This area should be free of obstacles and near the highest
point of your mission.
3. Switch on your remote control (Press the power button briefly, press it again and hold it until it powers on).
4. Install the battery (fully charged)
5. Turn on the Phantom (Same procedure remote control).
6. Connect your ground station (tablet) to the remote control using the supplied usb cable.
7. Plug in the battery to the Multispectral camera.(wait for the green light on the sunshine sensor)
8. Double press the button on the Multispectral camera to start taking pictures.
9. Press the Start button on aerobotics app..
10.The phantom will automatically take off
11. Monitor the mission from the ground station.
12. Once the mission is completed the Phantom will return home and automatically land and disarm
13.Stop the mapping camera and unplug
14.Upload data. This can be done after multiple flights.

dji PHANTOM 4 Specifications

General

Product color	White
Frequency band	2.4 - 2.483 GHz
GPS (satellite)	Yes
Number of rotors	4 rotors
Maximum weight capacity	- kg
Maximum operating distance	5000 m
Number of propeller blades	2
Moving control functions	Downward, Forward, Turn left, Turn right, Upward
Cables included	USB
Memory card included	MicroSD
Megapixel	12 MP
Video resolutions	1280 x 720, 1920 x 1080, 2704 x 1520, 3840 x 2160, 4096 x 2160 pixels
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Maximum video resolution	4096 x 2160 pixels
Compatible memory cards	MicroSD (TransFlash)
Battery voltage	7.4 V
Battery capacity	6000 mAh

Weight and Dimensions

Width	289.5 mm
Height	196 mm
Weight	1380 g
