dji PHANTOM 4 Flight Manual

Charging the Batteries
Notes
• You must fully charge the battery before your first flight
• Always turn off the battery before inserting it or removing it from the Phantom 4
• Never insert or remove the battery when it is active
Charging the Battery
• Connect the Battery charger to a power source
• Open the protection cap and connect the Intelligent Flight Battery to the Battery
Charger
• The Battery Level Indicator (LEDs) will display the current charge level
• The battery is fully charged when all of the LEDs have turned off
• Air-cool the battery after each flight, allowing it to reach room temperature before
storage
Notes
• Batteries must be charged using a DJI approved adapter (warranty will be voided if a
non-DJI charger causes issues)
• Wherever possible, don’t leave the battery unattended during charging

dji PHANTOM 4 Specifications

General

Product color	White
Frequency band	2.4 - 2.483 GHz
GPS (satellite)	Yes
Number of rotors	4 rotors
Maximum weight capacity	- kg
Maximum operating distance	5000 m
Number of propeller blades	2
Moving control functions	Downward, Forward, Turn left, Turn right, Upward
Cables included	USB
Memory card included	MicroSD
Megapixel	12 MP
Video resolutions	1280 x 720, 1920 x 1080, 2704 x 1520, 3840 x 2160, 4096 x 2160 pixels
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Maximum video resolution	4096 x 2160 pixels
Compatible memory cards	MicroSD (TransFlash)
Battery voltage	7.4 V
Battery capacity	6000 mAh

Weight and Dimensions

Width	289.5 mm
Height	196 mm
Weight	1380 g
