dji PHANTOM 4 Flight Manual

Calibrations
Dji Phantom 4 - IMU
•
Choose a very flat surface for the Phantom 4 IMU calibration (very important)
•
Remove the propellers before you start the compass calibration
•
Have your batteries fully charged in the Phantom 4 quadcopter, the Remote Control and your tablet of smart cellphone
•
Next, start up the Phantom 4 Remote Controller
•
Start the DJI Go App
•
Start up the Phantom 4 quadcopter
•
In the DJI Go App, click on the “Camera” settings
•
Up in the left hand corner, click on the little quadcopter (attitude) button which is the main settings page
•
Scroll down and click on the “Advanced Settings”
•
Click on “Sensors”
•
Click on “IMU Calibration”
•
Click on “Start Calibrating”
•
A popup message will appear saying “Calibration Requires Approximately 5 Minutes. Do Not Move Aircraft During
Calibration”
•
Click Ok and the IMU calibration will start
•
Then next page will show you the IMU calibration progress. Stay on this page during the Phantom 4 IMU calibration.
•
When the calibration reaches 100%, a popup message will appear stating “Calibration Complete. Restart Aircraft”
•
Click ok
•
Power down and then restart the Phantom 4 to complete the calibration process
•
You will need to power down the Phantom 4 again and then put back on the propellers

dji PHANTOM 4 Specifications

General

Product color	White
Frequency band	2.4 - 2.483 GHz
GPS (satellite)	Yes
Number of rotors	4 rotors
Maximum weight capacity	- kg
Maximum operating distance	5000 m
Number of propeller blades	2
Moving control functions	Downward, Forward, Turn left, Turn right, Upward
Cables included	USB
Memory card included	MicroSD
Megapixel	12 MP
Video resolutions	1280 x 720, 1920 x 1080, 2704 x 1520, 3840 x 2160, 4096 x 2160 pixels
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Maximum video resolution	4096 x 2160 pixels
Compatible memory cards	MicroSD (TransFlash)
Battery voltage	7.4 V
Battery capacity	6000 mAh

Weight and Dimensions

Width	289.5 mm
Height	196 mm
Weight	1380 g
