dji RC Plus Quick Start Guide

EN
10
Specications
O3 Pro
Operating Frequency
[1]
2.4000-2.4835 GHz; 5.725-5.850 GHz
Max Transmission Distance
[2]
(unobstructed, free of interference)
15 km (FCC); 8 km (CE/SRRC/MIC)
Max Transmission Distance
[2]
(with interference)
Strong Interference (urban landscape, limited line of sight, many competing signals): 1.5-3 km (FCC/CE/SRRC/MIC)
Medium Interference (suburban landscape, open line of sight, some competing signals): 3-9 km (FCC); 3-6 km (CE/SRRC/MIC)
Weak Interference (open landscape abundant line of sight, few competing signals): 9-15 km (FCC); 6-8 km (CE/SRRC/MIC)
Transmitter Power (EIRP)
2.4 GHz: <33 dBm (FCC); <20 dBm (CE/SRRC/MIC)
5.8 GHz: <33 dBm (FCC); <14 dBm (CE); <23 dBm (SRRC)
Wi-Fi
Protocol Wi-Fi 6
Operating Frequency
[1]
2.4000-2.4835 GHz; 5.150-5.250 GHz; 5.725-5.850 GHz
Transmitter Power (EIRP)
2.4 GHz: <26 dBm (FCC); <20 dBm (CE/SRRC/MIC)
5.1 GHz: <26 dBm (FCC); <23 dBm (CE/SRRC/MIC)
5.8 GHz: <26 dBm (FCC/SRRC); <14 dBm (CE)
Bluetooth
Protocol Bluetooth 5.1
Operating Frequency 2.4000-2.4835 GHz
Transmitter Power (EIRP) <10 dBm
General
Model RM700
Screen 7.02-in LCD touchscreen, with a resolution of 1920×1080 pixels, and high brightness of 1200 cd/m
2
Internal Battery Li-ion (6500 mAh @ 7.2 V), Chemical System: LiNiCoAIO2
Charging Type It is recommended to use USB-C chargers with maximum rated power of 65W and maximum voltage of 20V
Rated Power 12.5 W
Storage Capacity 64GB + expandable storage via microSD card
Charging Time 2 hours (using a USB-C chargers with maximum rated power of 65W and maximum voltage of 20V)
Operating Time Internal Battery: Approx. 3 hours and 18 min; Internal Battery + External Battery: Approx. 6 hours
Ingress Protection Rating IP54
GNSS GPS+Galileo+BeiDou
Video Output Port HDMI Type-A
Operating Temperature -20° to 50° C (-4° to 122° F)
Storage Temperature Range
Less than one month: -30° to 45° C (-22° to 113° F);
One to three months: -30° to 35° C (-22° to 95° F);
Three months to one year: -30° to 30° C (-22° to 86° F)
Charging Temperature 5° to 40° C (41° to 104° F)
Supported Aircraft Models
[3]
M30, M30T
[1] 5.8 and 5.1GHz frequencies are prohibited in some countries. In some countries, the 5.1GHz frequency is only allowed for use in indoor.
[2] DJI RC Plus is capable of supporting various DJI aircraft and the parameters vary depending on the aircraft.
[3] The DJI RC Plus will support more DJI aircraft in future. Visit the ocial website for the latest information.

dji RC Plus Specifications

General

Screen Size	7 inches
Brightness	1200 cd/m²
Wi-Fi Protocol	802.11 a/b/g/n/ac
Bluetooth Operating Frequency	2.4 GHz
Video Output Port	HDMI
Operating System	Android
Screen Resolution	1920 x 1200
Operating Temperature	-20° to 45° C (-4° to 113° F)
Connectivity	USB-C, HDMI
Wi-Fi Operating Frequency	2.4 GHz, 5.8 GHz
Operating Frequency	2.400-2.4835 GHz; 5.725-5.850 GHz
Max Transmission Distance	15 km
GNSS	BeiDou
Charging Time	Approximately 2 hours
Compatibility	DJI Matrice 30 Series
Battery Life	Approx. 6 hours
