dji SPARK Manual

Settings
General Settings
Here you can calibrate the Spark and choose some basic
settings such as measurement units (imperial / metric)
VR settings
Basic settings for VR view
RTH settings
Here you change the Altitude of the RTH also you can set the
FailSafe Behaviour
Flight Limit settings
Here you can set the Max altitude and distance for your
flight
Hardware Decoding Option
In setting you can choose hardware decoding ON/OFF, it’s recommended to keep it ON on all device with “A8” chip
or newer (iPhone 6/iPad Mini 4/iPad Air 2 or newer devices) this will reduce video latency also will reduce the over
heating/battery consumption of the device.

dji SPARK Specifications

Operating Environment

max speed	31 mph (50 kph)
operating temperature	32° to 104° F (0° to 40° C)
charging temperature	41° to 104° F (5° to 40° C)

Camera

sensor	1/2.3” CMOS
effective pixels	12 Megapixels
video recording modes	FHD: 1920×1080 30p

Power

charger input	100-240 V, 50/60 Hz, 0.5 A
charger output	5 V 3 A / 9 V 2A / 12 V 1.5 A
battery capacity	1480 mAh

Remote Control

operating frequency	2.4G / 5.8G
max transmission distance (Wi-Fi)	100 m (Distance), 50 m (Height)
max transmission distance (Remote Controller)	2000 m

Weight and Dimensions

weight	300 g
dimensions	143×143×55 mm
