DJI Three-Channel Follow Focus
User Guide
EN
2
Introduction
The DJI
TM
Three-Channel Follow Focus can be attached to the DJI High-Bright Remote Monitor so
users can wirelessly control the focus, iris, and zoom when using a zoom lens and also to start and
stop recording with the camera. The illuminated focus marking ring and iris marking strip make the
follow focus easy to use even in dark environments.
Installation
1. Turn over the follow focus. Align the monitor rotating bracket with the threaded hole closest to
the pin connector on the follow focus, and turn the lever clockwise until it is tight and secure.
Align the positioning notch on the plain white marking ring with the positioning marker on the
focus knob and lock into place to install the marking ring on the focus knob.
(Figure 1)
2. Remove the two screws to remove the remote monitor cage from the DJI High-Bright Remote
Monitor.
(Figure 2)
3. Align the threaded holes on the monitor rotating bracket with the threaded holes on the monitor
and install and tighten the two thumb screws. After the installation is completed, press the power
button on the left side of the monitor to power on the monitor and the follow focus together.
(Figure 3)
1 2
3
