dji ZENMUSE P1 Quick Start Guide

3
EN
are proper and in accordance with all applicable laws, rules, and regulations, including international and
domestic airspace regulations, and all terms, precautions, practices, policies, and guidelines DJI has
made and may make available.
DJI accepts no liability for damage, injury, or any legal responsibility incurred directly or indirectly from the
use of this product. The user shall observe safe and lawful practices including, but not limited to, those
set forth in the user manual.
In the Box
Gimbal and Camera (inc. SD
Card and microSD Card) × 1
Storage Case × 1 Camera Body Cap × 1
Lens Rear Cap × 1 Lens Cleaning Cloth × 1
Introduction
The Zenmuse P1 integrates a 45MP full-frame sensor, a global mechanical shutter, and an interchangeable
xed-focus DJI DL Lens (ENTERPRISE) on a 3-axis stabilized gimbal. Designed to be used with compatible
DJI aircraft and DJI TERRA
TM
for photogrammetry ight missions, the P1 takes eciency and accuracy to a
whole new level.

dji ZENMUSE P1 Specifications

General

Country of origin	China
Power consumption (max)	20 W
Product color	Black
Compatible products	DJI Matrice 300 RTK
International Protection (IP) code	IPX4
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	-20 - 60 %
Megapixel	45 MP
Maximum image resolution	8192 x 5460 pixels
ISO sensitivity	100, 25600
Image stabilizer	Yes
Maximum aperture number	16
Minimum aperture number	2.8
Field of view (FOV) angle	63.5 °
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	1 s
Compatible memory cards	SD
Maximum memory card size	512 GB
Maximum frame rate	60 fps
Video formats supported	MOV, MP4
Maximum video resolution	3840 x 2160 pixels
Mechanical pan range	-320 - 320 °
Mechanical roll range	-55 - 55 °
Mechanical tilt range	-130 - 40 °
Wi-Fi	-

Weight and Dimensions

Depth	129 mm
Width	166 mm
Height	198 mm
Weight	800 g
