Gen.1 - v.230227 | 11
PACKAGE CONTENTS
A1 x1 A2 x1 A3 x1 A4 x1
Base Hitch Lock M16x95 Screw Ø16 Lock Washer
A5 x1 A6 x1 B x8 C x8
Ø16 Washer Hitch Lock Keys M8x20 Screw Ø8 Washer (Large)
D1 x1 D2 x1 D3 x2 D4 x2
Inner Rack Outer Rack Front Wheel Cradle Rear Wheel Cradle
D5 x2 D6 x4 D7 x2 D8 x2
M8x105 Adjustment Handle Base M8 Adjustment Handle M8x80 Screw Ø8 Washer (Small)
D9 x2 D10 x2 D11 x1 D12 x1
M8 Hex Nut M6x20 Screw Bike Keys Ramp Bracket
D13 x1 E x1 F x1 G x1
Ramp Safety Strap S13 Wrench S5 Allen Key
