A. Welding D.Hardware
No Description Qty
No Description Qty No Description Qty
No Description Qty
A1 Main frame 1 A6 Incline bracket 1 D1 Allen wrench 80X80XT5mm 1
D22 Cross head screw M6X65 6
A2 Base frame 1 A7 Adjustable outer tube 1 D2 Allen wrench 80X80XT6mm 1
D23 Self-tapping screw ST3.5X16 2
A3L Left upright 1 A8 Adjustable inner tube 1 D3 Round hex bolt M10X50 4
D24 Self-tapping screw ST4.2X25 4
A3R Right upright 1 A9 Filter bracket 1 D4 Round hex bolt M8X65 2
D25 Self-tapping screw ST4.2X16 30
A4 Handrail bracket 1
A10 Safety plate 1 D5 Round hex bolt M10X15 4
D26 Screw M5X20 4
A5 Cross bar 1
D6 Round hex bolt M10X45 1
D27 Screw M5X15 4
B.Plastic parts D7 Round hex bolt M8X55 4
D28 Screw M5X8 4
No Description Qty
No Description Qty D8 Round hex bolt M8X15 6
D29 Self-tapping screw ST4.2X25 8
B1 Computer chip 1 B15 Transport wheel 4 D9 Round hex bolt M8X30 4
D30 Nylon nut M10 5
B1-1 Overlay 1 B16 Adjust wheel 2 D10 Round hex bolt M8X35 2
D31 Nylon nut M8 18
B1-3 Computer panel 1 B17 Handrail foam 1 D11 Round hex bolt M8X40 1
D34 Flat washer M10 11
B2 Computer bottom cover 1 B18 High cushion 6 D12 Round hex bolt M8X45 1
D35 Flat washer M8 21
B3 Motor cover 1 B19 Rubber cushion 2 D13 Round hex bolt M8X50 4
D36 Flat washer M5 4
B4 Right handrail cover L 1 B20 Cushion 2 D14 Round hex bolt M8X60 2
D37 Washer 8
B5 Right handrail cover R 1 B21 Flat end cap 4 D15 Round hex bolt M8X110 1
D38 Spring washer M8 4
B6 Silicon oil 2 B22 Protect wire plug 2 D16 Round hex bolt M8X55 1
D39 Spring washer M5 2
B7 Non-slim sticker 1 B23 Side rail 2 D17 Round hex bolt M8X60 2
D40 Inner washer M8 8
B8 Handle pulse 2 B24 Left handrail cover L 1 D18 Round hex bolt M10X20 2
D41 Cross head screw M4X10 14
B9 Safety key house 1 B25 Left handrail cover R 1 D19 Round hex bolt M8X20 4
D42 Screw driver13-15-17 1
B10 Inner plug 4 B26 Bookcase 1 D20 Cross head screw M6X25 2
D43 Spring bushing 1
B11 Left side cover 1 B27 EVA cushion 1 D21 Cross head screw M6X40 2
B12 Right side cover 1 B28 Round plug D38 1
B13 Left end cap 1
B29 Round plug D32 1
B14 Right end cap 1
B30 Inner tube plug 1
B31 Square inner plug 2
C. Electrical parts
No Description Qty
No Description Qty
C1 Incline motor 1
C13 Filter 1
C2 AC Motor 1 C14 Single ground line 1
C3 Power switch 1 C15 Single line 2
C4 Power code 1 C16 Single line 2
C5 Outlet 1 C17 Running board 1
C6 Safety key 1 C18 Cylinder 2
C7 Computer upper wire 1 C19 Rear roller 1
C8 Computer middle wire 1 C20 Front roller 1
C9 Magnetic ring 1 C21 Motor belt 1
C11 Inverter 1 C22 Running belt 1
C12 Overload protector 1 C23 Inductor 1
C24 Computer lower wire 1
