GS R/C
DLA ENGINE OPERATING-INSTRUCTION
MANUAL
04-21-21 Copyrighted Material
Owner’s Manual All Rights Reserved 03180-10000
Page - 36 DLA 32, 58, 64, 64-I2, 116, 116-I2 & 128cc, 180c, 232cc Rev. A.05.15
DLA 58
Dwg
Key #
Part Description
03180-01205
1
Cylinder Head, 58cc, Straight Plug Config., 1-pcs, per each
01380-01243 1S
Cylinder Head, 58cc, Slanted Spark Plug Config, 1-pcs, p[er each
03180-01207
3 Crank Case, Front & Rear, 58cc
03180-01206 2 Crankshaft & Connecting Rod, 58cc
03180-01246 40 Con-Rod, 58cc
03180-01225 21 Propeller Shaft, Crankshaft Extension, 58cc
03180-01233
49 Key, Woodruff
03180-01213 9 Standoffs, Engine Mounting, & Bolts, 58cc
03180-01208
4 Piston & Wrist Pin w /retainers, 58cc
03180-01209 5 Ring, Piston, 58cc
03180-01228
5B
Rings, BOWMAN, 58cc / 116cc / 232cc
03180-01222 18 Wrist-Pin, Piston, , Con-rod, 58 / 116cc
03180-01226 22 Retainers, Piston Wrist Pin
03180-01210
6 Ignition Module, 58cc, Capacitive Discharge.
03180-01214 10 Spark Plug, Iridium, all engines
03180-01217 13 Sensor, Ignition, w/mounting screws
01380-01239 37 Tachometer
03180-01211
7
Muffler, Std-CAN, 58cc, 1-pcs, per each (Specifly Left or Right)
01380-01144 36
Muffler, Pitts Style, 58cc
03180-01245 42
Muffler, Canister, 58cc
03180-01212
8
Carburetor, 58cc, Complete, Walbro, HDA, WT-247
03180-01215 11 Reed Valve Assembly, Carburetor, 58cc, 2-pcs, per set
03180-01233
30 Reeds Only, Reed-Value, 58 / 64cc, 2-pcs, per set
03180-01232 29 Housing, Reed-Valve (Heat Blocking), 58 / 64cc, 1-pcs, per each
03180-01220
16 Hub, Propeller, Washer, Propeller, 58 / 64cc
03180-01237
34
Prop-Hub (Only), 58 / 64cc
03180-01236 33
Prop Washer, Only, 58cc
03180-01216
12
Bearing Set, Front & Rear, Crankshaft, (FAG), 58cc, 2-pcs, per set
03180-01216-F 12-F Bearing, Front, Crankshaft, (FAG), 58cc, 1-pcs, per each
03180-01216-M 12-M Bearing, Main, Crankshaft, (FAG), 58cc, 1-pcs, per each
03180-01221 17 Bearing Needle, Connecting-rod wrist-pin, 58c / 116cc / 232cc, 13mm
03180-01219
15 Bolt Set, Complete,Mounting, Muffler, Prop Casem, 58cc, 26-Pcs, Per Set
03180-01238 35 Bolts, Muffler, 500 x 0.8 - 16 mm, (2 ea)
03180-01219-P 42 Bolts, Prop. 5mm, 4-pcs, Per Set
03180-01219-H 15H Bolts, Head, 5mm, 4-pcs, Per Set
03180-01247 41 Bolts, Carburetor, 2-pcs, Per Set
03180-01219-C 15-C Bolts, Crankcase, 4-pcs, Per Set
03180-01219--M 15-M Bolts, Mounting, 4-pcs, Per Set
03180-01218
14 Gasket Set, Muffler, Carb, Head, Induction Stack, 58cc, 5-pcs, Per Set
03180-01234
39 Gasket, Muffler, 58cc, 1-pcs, Per each
03180-01230
27 Gasket, Cylinder Head, 58cc 1-pcs. Per Each
03180-01231
14-H Gasket, Carburetor, 58cc, 1-pcs, Per Each
03180-01235 14-I Gaskets, Induction Stack, 58cc, 3-pcs, Per Set
03180-01223 19 Puffer - Line, Carb to Reed Valve Assembly
Gaskets
DLA 58cc PARTS LIST - Rev: A.08
Part Numbers - Engine Components
(See www.goldenskiesrc.com for current lists and Prices)
Heads
Crankcas&
Crankshaft
Pistons
& Rings
Ignition
Mufflers
Induction
Stack
Hubs
Bearings
Bolts
Functional
Groupings
