DLA 32cc - Page 38

GS R/C
DLA ENGINE OPERATING-INSTRUCTION
MANUAL
04-21-21 Copyrighted Material
Owner’s Manual All Rights Reserved 03180-10000
Page - 38 DLA 32, 58, 64, 64-I2, 116, 116-I2 & 128cc, 180c, 232cc Rev. A.05.15
DLA 64
Dwg
Key #
Part Description
STOCK
03180-01105 1
Cylinder Head, 32 / 64 / 128cc, Straight Sparkplug Configuration, per each
IN
103180-01105-S
1S
Cylinder Heads, 32 / 64 / 128cc, Slanted Spark Plug Configuration, per each
IN
03180-00301
2
Crankshaft & Connecting Rod, 64cc Twin Boxer, 1-pcs, per each
IN
03180-01224 3 Propeller Shaft, Crankshaft Extension, 32 / 64 / 128cc, 1 pcs, per each
IN
03180-00302 4 Crank Case, Front & Rear, 64cc Twin Boxer, 2 pcs, per set
IN
03180-01109
5
Piston & Wrist Pin & Retainers. 32 / 64 / 128cc (4 pcs). Per set
IN
03180-01122 6 Wrist-Pin, Piston, Con-rod, 32 / 64 / 128cc, 1-pcs, per each
IN
03180-01126 7 Retainers, Piston Wrist Pin, (All Engines), 4 pcs, per set
IN
03180-01109 8 Ring, Piston, 32 / 64 / 128cc, 1 pcs, per each
IN
03180-01109-B
9
Rings, BOWMAN 32, 64, 128cc, 1 pcs, per each
IN
03180-01110
10
Ignition Module, Capacitive Discharge, 64cc Twin Boxer, per each
IN
03180-01114 11 Spark Plug All Engines, 1 pcs, per each
IN
03180-01115 12 Plug & Copper Gasket, Sparkplug Hole, All Engines. 2-pcs, per set
IN
03180-00117 13 Sensor, Ignition, w/mounting screws, All Engines, 1-pcs, per each
IN
03180-00303
14
Muffler, 64cc Twin Boxer, 1-pcs, per each
IN
01380-01142
15
Muffler, Canister, Includes: Muffler, Header, and coupler/clamps (1 each), 32 & 64cc (2 required for 64cc)
IN
03180-01212
16
Carburetor, 64cc, Complete, 58 / 64cc Walbro HAD, 1-pcs, per each
IN
03180-01215 17 Reed Valve Assembly, Carburetor, 64cc Twin Boxer, 2-pcs, per set
IN
01380-00304 18 Base / Mount, Carburetor, 64cc, 1-pcs, per each
IN
03180-01232 19 Housing, Reed-Valve (Heat Blocking), 58 / 64cc, 1-pcs, per each
IN
03180-01233 20 Reeds Only, Reed-Value, 58 / 64cc, 2-pcs, per set
IN
03180-01220
21
Hub, Propeller, Washer, Propeller, 58 / 64cc, 2-pcs, per set
IN
03180-01237 22 Prop-Hub Only,58 / 64cc, 1-pcs, per each
IN
03180-01236 23 Prop Wash, 64cc, Only, 1-pcs, per each
IN
03180-01318 24 Standoffs, Engine Mounting, 64cc, 4-pcs, per set
IN
03180-00305 25
Bearing Set, Front, Middle & Rear, Crankshaft (FAG), 64cc Twin Boxer, 3-pcs, per set
IN
03180-00305-F 26 Bearing, Front, 1-pcs, per each
IN
03180-00305-M 27 Bearing, Main, 1-pcs, per each
IN
03180-00305-E 28 Bearing, End, 1-pcs, per each
IN
03180-01121 29 Bearing Needle, Connecting-rod wrist-pin, 32 / 64cc, 12mm, 1-pcs, per each
IN
03180-00306
30
Bolt-Set, 24-pcs, per set
IN
03180-00307 31 Bolts, Muffler, All Engines, 2-pcs, per set of 2
IN
03180-00308 32 Bolts, Head / Cylinder, 4-pcs, per set of 4
IN
03180-00310 34 Bolts, Crankcase, 4-pcs, per set of four.
IN
03180-00311 35 Bolts, Stand-offs, 8-pcs, per set of 8
IN
03180-00312 36 Bolts, Carburetor, 2-pcs, per set of 2
IN
03180-00313 37 Bolts, Carburetor - Mounting Plate, 2-pcs, per set of 2
IN
03180-00314 38 Bolts, Propeller, 4-pcs, per set of 4
IN
03180-00315 39 Gasket Set, 64cc, 8-pcs, per set of 8
IN
03180-00316 40 Gasket, Muffler, 32 / 64 / 128cc, 2-pcs, per set of 2
IN
03180-00317 41 Gasket, Cylinder Head, 32 / 64 / 128cc, 2-pcs, per set of 2
IN
03180-00318 42 Gaskets - Induction Stack, 64cc, 4-pcs, per set of 4
IN
03180-00319 43 Gasket Carburetor, 1-pcs, per each
IN
03180-00320
44
Key, Woodruff, 64c, 1-pcs, per each
IN
01380-01239 45 Tachometer, (All DLA Engines), 1-pcs, per each
IN
03180-00321 - Header, Canister, 64cc, 1-pcs, per each
IN
Part Numbers - Engine Components
Prices Subject to Change without Notice on this Page
CRANK
SHAFT
PISTONS
INGNITION
Mufflers
INDUCTION
STACK
PROP
HUBS
BEARINGS
BOLTS
GASKETS
DLA 64cc PARTS LIST - Rev: A.08
FUNCTIONAL
GROUPINGS
HEADS
