DLA 32cc - Page 40

GS R/C
DLA ENGINE OPERATING-INSTRUCTION
MANUAL
04-21-21 Copyrighted Material
Owner’s Manual All Rights Reserved 03180-10000
Page - 40 DLA 32, 58, 64, 64-I2, 116, 116-I2 & 128cc, 180c, 232cc Rev. A.05.15
Part Numbers - Engine Components
(See www.goldenskiesrc.com for current lists and Prices)
DLA 64-I2
Dwg
Key #
Part Description
03180-01105 1
Cylinder Head, 32 / 64 / 128cc STRAIGHT PLUG Conf., per each
03180-01127
1-S Cylinder Head, 32 / 64 cc SLANTED PLUG Conf., 1-pc, per each
03180-00702 2
Short-Block 64-I2 - Assembled, , Incls: Crankcase, Crankshaft, Con-rods,
03180-00709
14
Standoffs, Engine Mounting, 64-I2 cc. per set of 4
03180-01324
19
Propeller Shaft, Crankshaft Extension, 58 / 64 / 64-I2, per each
03180-01319 15
Hub & Washer, Propeller, 64, 58, 64-I2. 2-pcs
03180-01335 28
Prop-Hub (Only), 58 / 64 / 64-I2 cc, per ach
03180-01133 18 Key, Woodruff, All New Engines, 13.7 x 4.33 x 3 mm, per each
03180-01337
30
Prop Wash, Only. 58 / 64 / 64-I2, per each
03180-01108
3 Piston, 32 / 64 / 128cc (Incls: Wrist-pin & 2 ea retainer clips), per each
03180-01109 4 Ring, Piston, 32, 64, 128cc, per each
03180-01128 22
Rings, BOWMAN 32, 64, 64-I2, 128cc, per each
03180-01126 38
Retainers, Piston Wrist-Pin, 32 / 64 / 64-I2 / 128cc, set of 4 pcs
03180-01122
21
Wrist-Pin, Piston, , Con-rod, 32 / 64 / 64-I2 / 128 cc, per each
03180-01110
5 Ignition Module, Capacitive Discharge., 32cc / 58cc / 64-I2 / 116-I2 (ea)
03180-00117 26 Sensor, Ignition, All Engines, w/mounting screws, per each
03180-01114 9 Spark Plug, Iridium, Universal, per each
03180-01115 12 Plug & Copper Gasket, Sparkplug Hole, All Engines. 2-pcs, per set
01380-01239 37 Tachometer, (All DLA Engines)
03180-00703 6
Muffler, 64-I2 cc In-line, per each
01380-01143 35
Muffler, Canister, Includes: Muffler, Header, and coupler/clamps (1 each), 32 & 64cc (2 required for 64cc)
03180-01112
7 Carburetor, 32 / 64-I2cc, Complete, Tillotson HU-134A, 32cc, per each
03180-00705 10
Reed Valve Assembly - Induction Stack, 64-I2, Carburetor, per each
03180-00712 27
Reed Valve, 64-I2, Only, per each
03180-00710 17
Heat Block, Reed Valve Housing, 64-I2, per each
03180-00713 10
Adapter-Base, Reed-Valve, Carburetor, 64-I2, per each
03180-00714
40
Choke & Throttle Connecting Linkage and Ball-end Connectors, 64-I2 (ea)
03180-00706
11
Bearing Set, Front, Rear, 64-I2 Crankshaft (FAG)
03180-01121 16
Bearing Needle, Connecting-rod wrist-pin, 32 / 64 / 128cc, 12 mm, ea
03180-00715
41
Bolt Set Complete, 28-pcs, Per Set
03180-00704 8 Bolt-Set, Mount, 4-pc, Per Set
03180-00707 12 Bolts, Muffler or Head, 1-pcs, per each
03180-00716 42 Bolts, Carburetor, 64-I2, 1-pcs, per each (2-reqired)
03180-01341 40 Bolts, Propeller, 4-pcs, Per Set
03180-00708 13
Gasket Set, 64-I2, Muffler, Carburetor / Induction Stack, Cylinder Head, 12 pcs
03180-00711 13-C
Gasket, Carburetor, 64-I2 cc, 1 pc, per each
03180-01331 24
Gasket, Muffler. 32 / 64 / 64-I2 / 128 cc, 1-pcs,per each
03180-01130 13-H Gasket, Cylinder Head, 32 / 64 / 128cc, 1-pcs, per each
03180-01340 13-I
Gaskets, Induction Stack, 32 / 64 / 64-I2 cc, 4-pcs, Per Set
DLA 64CC-I2 Parts List Rev: A 8.00
FUNCTIONAL
GROUPINGS
