DLA ENGINE OPERATING-INSTRUCTION
MANUAL
04-21-21 Copyrighted Material
Owner’s Manual All Rights Reserved 03180-10000
Page - 44 DLA 32, 58, 64, 64-I2, 116, 116-I2 & 128cc, 180c, 232cc Rev. A.05.15
Cylinder Head, 58, 116, 232 cc, Straight Plug Config, Per each
Cylinder Head, 58cc, Slanted Spark Plug Configuration, per each
03180-02434 24 Mount Base, Ring, 1-pcs, per each
03180-02418 -
Standoffs, Engine Mounting, 116-I2cc, 4-pcs, per set
Propeller Shaft, Crankshaft Extension. 116 / 116-I2, 1-pcs, per each
03180-01133 - Key, Woodruff, All New Engines, 1-pcs, per each
03180-01419 14
Hub, & Washer, Propeller, 116cc, 116cc-I2, 128cc, 2-pcs, per set
Prop-Hub, Only, 116 / 116-I2cc, 1-pcs, per each
03180-01429 19
Prop Wash, Only, 116cc, 116-I2, 128cc, 1-pcs, per each
03180-01208 3
Piston & Wrist Pin w /retainers, 58, 116, 232cc, 4-pcs, per set
03180-01209 4
Ring, Piston, 58, 116, 116-I2, 232 cc, 1-pcs, per each
03180-01228 4-B
Rings, BOWMAN, 58 / 116 / 232 cc, 1-pcs, per each
03180-01222 37
Wrist-Pin, Piston, , Con-rod, 58 / 116cc, 1-pcs, per each
03180-01425 -
Retainers, Piston Wrist-Pin, 4- pcs, per set
03180-01115
Plug & Copper Gasket, Sparkplug Hole, All Engines. 2-pcs, per set
03180-01110 -
Ignition Module, Capacitive Discharge., 32cc / 58cc / 64-I2 / 116-I2, 1-pcs, per each
03180-01114 9
Spark Plug, (All DLA Engines), 1-pcs, per each
03180-00117 -
Sensor, Ignition, w/mounting screws, 3-pcs, per set
01380-01239
-
Tachometer, (All DLA Engines), 1-pcs, per each
03180-02410 6
Muffler, CAN, each, 116-I2cc, 1-pcs, per each
Muffler, Cannister, 58 / 116cc, 1-pcs, per each
03180-01212 7
Carburetor, 58cc, 116-I2, Complete, Walbro HDA, 9cs, per each
03180-02414 10
Reed Valve / Induction Stack, 116-I2, Assembly, 2-pcs, per set
Heat Block / Reed Value Housing, 116-I2 cc, 1-pcs, per each
Choke or Throttle Connecting Linkage and Ball-end, per each link set
03180-01405
-
Air Filter, (All DLA Engines, 1-pcs, per each
-
Bearing Set, Front, Rear, 116-I2 Crankshaft (FAG), 2-pcs, per set
Bearing Needle, Con-rod wrist-pin, 58 / 116cc, 1-pcs, per each
03180-01438 26 Bolt-Set, All, 116-I2cc, 34-pcs, per set
03180-01416 -
Bolts, Muffler, (All DLA Engines), 4-pcs, per set of 4
03180-01412 34
Bolt-Set, Prop., 16-I2cc, 6-pcs, Per set
03180-02436 40
Bolts, Cylinder Head, 1-pcs, per each
03180-02405
38
Bolts, Carburetor, 5 x 0.8 mm, 1-pcs, per each
03180-02435 39
Bolts, Mounting Ring, 5 x 0.8 Flat Heat, 3mm Hex Dr, 4-pcs, per each
03180-02417
-
Bolts, Crankcase, 1-pcs, per each
03180-01432 22
Gasket, Cylinder Head, 58 / 116 / 232 cc, 1-pcs, per each
03180-02430 20
Gasket, Carburetor, 116-I2 cc, 1-pcs, per each
03180-01431 21
Gasket, Muffler, 58 / 116 / 232cc,1-pcs, per each
03180-00451
20 / 21
Gaskets, Induction Stack, 3-pcs, Per Set
03180-02442
-
Gaskets (2), Muffler, Bolts & Lockwashers, 116cc, 10-pcs, per set
DLA 116cc-I2 PARTS LIST - Rev: A.08
Part Numbers - Engine Components
(See www.goldenskiesrc.com for current lists and Prices)
SHORT BLOCK: Crankshaft & Connecting Rod, Crankcase (F/M//R), Bearings (7) , 116-I2 cc, In-Line
