03180-00907 1 Cylinder Head, Straight Plug Configuration, 180cc, 1-pcs, (per each)
IN
03180-00938 1-S
Cylinder Head,180cc, SLANTED PLUG Configuration, 1-pcs, per each
IN
03180-00909 3 Crank Case, Front & Rear, 180cc, 2-pcs,per set
IN
03180-00908 2 Crankshaft & Connecting Rod, 180cc, 1-pvs, per each
IN
03180-00926 20 Propeller Shaft, Crankshaft Extension, 116 / 180cc, per each
IN
03180-00922 28 Hub & Washer, Propeller, 180cc, per ser of 2-pcs, 1-pcs, per set
IN
03180-00935 16 Prop-Hub (Only), 180cc, 1-pcs, per each
IN
03180-00934 27 Prop Washer, Only, 180cc, 1-pcs, per each
IN
03180-00932 25 Key, Woodruff, 180cc, 1-pcs, per each
IN
03180-00931 44 Mount, Plate, 180cc, 1-pcs, per each
IN
03180-00915 9 Standoffs, Engine Mounting, & Bolts, 180, 4-pcs, per set
IN
03180-00910 4 Piston, 180cc, Wrist pin, Retainer Clips, 4-pcs, per set
IN
03180-00911 5 Ring, Piston, 180cc, 1-pcs, per each
IN
03180-00925 5-B
Rings, BOWMAN 180cc, 1-pcs, per set
Call
03180-00924 18 Wrist-Pin, Piston, Con-rod, 180cc, 1-pcs, per each
IN
03180-00927 - Retainers, Piston Pin, 180cc, 4-pcs, set
IN
03180-01310
- Ignition Module, Capacitive Discharge., 64/112/116/128/180cc, 1-pcs, per each
IN
03180-01114
10 Spark Plug, Iridium (All DLA Engines), 1-pcs, per each
IN
03180-00117
13
Sensor, Ignition, w/mounting screws (All DLA Engines), 3-pcs, per set
IN
03180-00950 49 Plug & Gasket, Sparkplug Cap, 2-pcs, per set
IN
01380-01239 - Tachometer, (All DLA Engines), 1-pcs, per each
IN
03180-00913 7
Muffler, CAN, 180cc, 2-pcs, per pair
IN
Muffler, Canister and Header Set, per set
IN
03180-00947 - Header, Cannister - 180cc, per each
IN
03180-00914 8
Carburetor, 180cc, Complete, Walbro WB 25-429, 1-pcs, per each
IN
03180-01414
11 & 30 Reed Valve Assembly, Carburetor, 180cc 2-pcs. per set
IN
03180-00928 22
Base, Carburetor, 1-pcs, per each
IN
03180-00939 11 Housing, Reed-Valve Heat Blocker, 180cc, 1-pcs, per each
IN
03180-00937 - Reed Values, Only, 180cc, 2-pcs, per set
IN
03180-00938 - Velocity Stack, Air Fiflter, 90 deg, 180cc, 1-pcs, per each
IN
03180-00918 12 Bearing Set, Front, Middle & Rear, Crankshaft (FAG), 180cc, 3-pcss, per set
IN
03180-00923 17 Bearing Needle, Connecting-rod wrist-pin (IKO Bearing, Japan),180cc, per each
IN
03180-00948
35-47-46-29-48-4550
Bolt Set, Complete, 32-pcs, per set
IN
03180-02033
35 Bolt, Prop 6 x 1.0 - 60 mm, 1-pcs, per each
IN
03180-00936 29 Bolt Set, Muffler, (all DLA Engines, 2-pcs, per set
IN
03180-00921 47
Bolt, Mounting, 180 / 232cc, 6.0 x 1.0 - 55 mm, 1-pcs, per each
IN
03180-00942 47S Bolt Set, Engine Mounting, w/washers & Nuts, Per Set of 16 pcs, per set
IN
03180-00941 45 Bolt, Carburetor Plate, 1-pcs, per each
IN
03180-00951 50 Bolt Set, Cylinder - Head, 4-pcs, per set
IN
03180-00949 48 Bolt Set, Crankcase, 4-pcs. set of 4 pcs
IN
03180-00920
Gasket Set, ALL, 180cc, 8-pcs, per set
IN
03180-00933 26 Gasket, Muffler,180cc, 1-pcs, per each
IN
03180-00930 24 Gasket, Carburetor, 180cc, 1-pcs, per each
IN
03180-00940 14 Gasket Set, Induction Stock, 4-pcs, per set
IN
03180-00929 23 Gasket, Cylinder Head, 180cc, 1-pcs, per each
IN
03180-00939 26S Gasket Set, Muffler, & Bolts / Lock washers, 180cc, 5-pcs, per set
IN
03180-00943 - Header, Muffler, 180cc, per each
IN
03180-00944 - Flange, Muffler, 180cc, per each
IN
03180-00945 - Flange, Adpater, 180cc, per each
IN
DLA 180 PARTS LIST - Rev: A.08.01
Part Numbers - Engine Components
Prices Subject to Change without Notice on this Page
CRANKCASE CRANKSHAFT
& HUBS
