DLA 128
Dwg
Key #
Part Description
Stock
03180-00602 2 Mount Plate, Rear, 128cc, 1-pcs, per each IN
03180-00620 41 Standoffs, Engine Mounting, 128cc, 4- pcs, per set of 4 IN
03180-01105
3
Cylinder Head, 32 / 64 / 128cc STRAIGHT PLUG Conf., 1-pcs, per each IN
03180-01127 4
Cylinder Head, 32 / 64 / 128cc SLANTED PLUG Conf., 1-pcs, per each
IN
03180-01108 5 Piston, 32 / 64 / 128cc (Incls: Wrist-pin & 2 ea retainer clips), 4-pcs, per set IN
03180-01109 6
Ring, Piston, 32 / 64 / 128cc, DLA Factory, 1-pcs, per each
IN
03180-01128 7
Rings, Piston, BOWMAN 32,64, 128cc, 1-pcs, per each
IN
03180-01122 8 Wrist-Pin, Piston, Con-rod, 32 / 64 / 128cc, 1-pcs, per each IN
03180-01126 9 Retainers, Piston Pin, 32 / 64 / 128cc, 2-pcs, per set IN
03180-01121 10 Bearing Needle, Connecting-rod wrist-pin, 32 / 64cc, 12mm (IKO Bearing) IN
10 11 Ignition Module, Capacitive Discharge., 64 / 112 / 116 / 128 / 180cc, 1-pcs, per each IN
03180-01114 12 Spark Plug, Iridium (All DLA Engines), 1-pcs, per each IN
03180-00117 13 Sensor, Ignition, w/mounting screws (All DLA Engines), 1-pcs, per each IN
03180-01116 14 Plug & Copper Gasket, Sparkplug Hole, All Engines. 2-pcs, per set IN
03180-01419
15
Hub, Propeller, Washer, Propeller, 116cc, 116cc-I2 128cc, 2-pcs, per set IN
03180-01440 16 Prop-Hub, Only, 116 / 128cc, 1-pcs, per each IN
03180-01429 17 Prop Wash, Only, 116 / 128cc, 1- pcs, per each IN
03180-01424 18 Propeller Shaft, Crankshaft Extension, 1-pcs, per each IN
03180-01133 40 Key, Woodruff, All New Engines, 13.7 x 4.33 x 3 mm, 1- pcs, per each IN
03180-01411 19
Carburetor, 116 / 128cc, Complete, Walbro WJ71 - 311
IN
03180-00603 20 BASE, Carburetor, 1-pcs, per each IN
03180-01215 21 Reed Valve Assembly, Carburetor, 64 / 128cc, 2-pcs, per set IN
03180-01435 22 Reed-Value Housing / Heat Block, 116 / 128cc, 1-pcs, per each IN
03180-00604 23 Bearing Set, Front & Rear, Crankshaft (FAG), 128cc, 1-pcs, per each IN
03180-01605 24 Bearing, Front, (FAG), 1-pcs, per each IN
03180-00606 25 Bearing, Rear, (FAG), 1-pcs, per each IN
03180-00607 26 Muffler, 128cc, per each, 1-pcs per each (Specify Left or Right) IN
03180-00632 42 Canister-Muffler, 1-pcs, per each IN
03180-01633 43 Header, Flexible, 1-pcs, per each IN
03180-00608 27 Gasket Set, Muffler, Carburetor, Head, 128cc, 16-pcs, per set IN
03180-01230 28 Gasket, Cylinder Head, 32 / 64 / 128cc, 1-pcs, per each IN
03180-00609 29 Gaskets, Induction Set, 4-pcs, per set IN
03180-00610 30 Gasket, Carburetor, 32 / 64 / 128cc, 1-pcs, per each IN
03180-00611 31 Gasket, Muffler, 2-pcs, per set of 2 IN
0318000612 32 Bolt Set Complete, 34-pcs, Per Set IN
03180-00613 33 Bolt Set: Muffler, 128cc, 4-pcs, per Set IN
03180-00614 34 Bolt, Propeller, 1-pcs, per each IN
03180-00615 35 Bolts, Mounting, Washers & Nut, 5-pcs, per set IN
03180-00616 36 Bolts, Head, 4- pcs, per set of 4 IN
03180-00617 37 Bolts, Mounting Plate to Crankcase, (Flat Head), 4-pcs, IN
03180-00618 38 Bolts, Carburetor Mounting Plate, 4-pcs, per Set IN
03180-00619 39 Bolts, Carburetor, 2-pcs, per Set of 2 IN
Muffler
Ignition
Front End
Heads
Drive Train
Part Numbers - Engine Components
(See www.goldenskiesrc.com for current lists and Prices)
Short
Block
03180-00601
1
Short-Block 128-Quad - Assembled, , Incls: Crankcase, Crankshaft, Con-rods,
1-Assembly, per assembly.
IN
FUNCTIONAL
GROUPINGS
DLA 128cc PARTS LIST - Rev: A.08.1
Induction
Stack
Bearings
Gaskets
Bolts
