DLA 32cc - Page 50

GS R/C
DLA ENGINE OPERATING-INSTRUCTION
MANUAL
04-21-21 Copyrighted Material
Owner’s Manual All Rights Reserved 03180-10000
Page - 50 DLA 32, 58, 64, 64-I2, 116, 116-I2 & 128cc, 180c, 232cc Rev. A.05.15
DLA 232
Part
Number
Dwg
Key #
Part Description
03180-01205
1
Cylinder Head, 58, 116, 232 cc, Straight Plug Config
01380-01243 1-S
Cylinder Head, 58cc, Slanted Spark Plug Configuration
03180-02020 19 Propeller Shaft, Crankshaft Extension, 232cc, ea
03180-02019 15 Hub, Propeller, Washer, Propeller, 232cc
03180-02022 25 Key, Woodruff, 232cc
03180-02024 26 Prop-Hub (Only, 232cc
03180-01223 25 Prop Washer, Only, 232cc
03180-01629 33 Mount Plate, Engine, Rear, 232cc
03180-02012 - Standoffs, Engine Mounting, & Bolts, 232cc
03180-01208 3 Piston & Wrist Pin w/retainers, 58, 116, 116-I2, 232cc
03180-01209 4 Ring, Piston, 58, 116, 116-I2, 232 cc
03180-01228 4-B
Rings, BOWMAN, 58cc / 116cc / 232cc, ea
03180-01222 17 Wrist-Pin, Piston, , Con-rod, 58cc / 116cc / 232cc. Ea
03180-01226 - Retainers, Piston Pin. 58cc / 116cc / 232cc. Set of 8
03180-02009 5 Ignition Module, Capacitive Discharge., 232cc
03180-01114 9 Spark Plug, Iridium (All DLA Engines)
03180-00117 12 Sensor, Ignition, w/mounting screws (All DLA Engines)
01380-01239 - Tachometer, (All DLA Engines)
03180-02010 -
Muffler, Can - Std, 232cc, (ea)
03180-01411 7
Carburetor, 116 / 232cc, Complete, Walbro WJ71 - 311
03180-02014 10 Reed Valve Assembly, Carburetor, 232cc
03180-01435 40 Heat Block / Reed-Value Housing, 116, 116-I2, 232 cc
03180-01223 - Reed Values, Only,232cc
01380-01225 39 Mounting Plate, Carburetor, 232cc, ea
03180-02031 -
Choke or Throttle Connecting Linkage and Ball-end Connectors, 232
Quad
03180-02015 11 Bearing Set, Front & Rear, Crankshaft (FAG), 232cc
03180-01221
-
Bearing Needle, Connecting-rod wrist-pin, 58c / 116cc / 232cc, 13 mm
03180-02034 14
Bolt Set, ALL, Complete, 54-pcs, per set
03180-02025 -
Bolt, Muffler, (all DLA Engines, ea)
03180-01338 36
Plug & Gasket, Sparkplug Hole, All Engines., 2-pcss, per set
03180-02033 34
Bolts, Prop 6 x 1.0 -60 mm, 1-pcs, per each
03180-01436 42
Bolts, Carburetor , 2 -pcs, per set
01380-01227 43
Bolts, Engine Mounting Plate, 1-pcs, per each
03180-01228 44
Bolt, Carburetor Mounting Plate, Flat Head, 1-pcs, per each
03180-02025 45
Bolt, Head, 5 x 0.8 -16 mm, 1-pcs, per each
03180-00947 37 Bolts, Nuts, Washers, Engine Mounting, 16-pcs, per set
03180-02018
-
Bolts, Crankcase, 4-pcs, per set
- Gasket Set, ALL, 18-pcs, per set
03180-01230 21
Gasket, Cylinder Head, 58cc / 116cc / 232cc. 1-pcs, per each
03180-02021 22
Gasket, Carburetor, 232cc, 1-pcs, per each
01380-01226 21-40-41
Gasket Set, Induction Stack, 232cc, 4-pcs, per set
03180-01234
24 / 31
Gasket, Muffler, 58cc / 116cc / 232cc, 1-pcs, per each
03180-01223 24-S
Gasket, Muffler, & Bolts / Lock washers, 232cc, 8-pcs, per set
DLA 232cc PARTS LIST - Rev: A.08
Part Numbers - Engine Components
(See www.goldenskiesrc.com for current lists and Prices)
Short-Block 232-Quad - Assembled, , Incls: Crankcase, Crankshaft,
Con-rods, All Main Bearings. Gasket Set.
03180-02006
2
