DLA 32cc - Published Specifications and Bolt Torques

GS R/C
DLA ENGINE OPERATING-INSTRUCTION
MANUAL
04-21-21 Copyrighted Material
Owner’s Manual All Rights Reserved 03180-10000
Page - 59 DLA 32, 58, 64, 64-I2, 116, 116-I2 & 128cc, 180c, 232cc Rev. A.05.15
Table 2 - DLA Published Specifications
DLA 32cc (1.97 in
3
) Gas Engine
Power: 3.8 HP @ 8200 rpm
Idle Speed: 1,350 - 1,700 rpm
Static Thrust: 19.4 pounds @ 100 m (~328 ft) (Pulling Force)
17.2 pounds @ 1,800 m (~5,900 ft)
Propellers: 18 x 8 / 10, 19 x 8, 20 x 8
Carburetor: Tillotson™, HU-134A
CDI Voltage: 6.4 – 8.4 VDC
Spark Plug: CM-6 Special, Iridium
Exhaust Volume: 32.23 cc (1.97 in
3
)
Cylinder Diameter / Stroke: 37 mm / 30 mm (1.46 in / 1.18”)
Compression Ratio: 7.6 : 1
Gas : Oil Ratios: 25 – 30 : 1 Break-in Trial Run; 40 – 50 : 1 Normal Flying
Weights: Engine 32.1 oz, Muffler: 2.3 oz, Ignition 3.5 oz
DLA 58cc (3.54 in
3
) Gas Engine
Power: 6.0 @ HP @ 8500 rpm
Idle Speed: 1,400 -1,500 rpm
Static Thrust: 33.1 pounds @ 100 m (~328 ft) (Pulling Force)
29.1 pounds @ 1,800 m (~5,900 ft)
Propellers: 22 x 10, 23 x 8/10, 24 x 8
Carburetor: Walbro™, “WT-xxx” Series
Spark Plug: CM-6 Special, Iridium
CDI Voltage: 6.4 – 8.4 VDC
Exhaust Volume: 58 cc (3.54 in
3
)
Cylinder Diameter / Stroke: 46 mm / 35 mm (1.77 in / 1.38”)
Compression Ratio: 7.8 : 1
Gas : Oil Ratios: 25 – 30 : 1 Break-in Trial Run; 40 – 50 : 1 Normal Flying
Weights: Engine 49.1 oz, Muffler: 3.87 oz, Ignition 4.76 oz
DLA 64cc (3.91 in
3
) Gas Engine (Twin Boxer)
Power: 7.2 @ HP @ 8500 rpm
Idle Speed: 1,400 rpm
Static Thrust: 34.4 pounds @ 100 m (~328 ft) (Pulling Force)
30.4 pounds @ 1,800 m (~5,900 ft)
Propellers: 22 x 10, 23 x 8/10, 24 x 8
Carburetor: Walbro™. “WT-xxx” Series
CDI Voltage: 6.4 – 8.4 VDC
Spark Plug: CM-6 Special, Iridium
Exhaust Volume: 64 cc (3.97 in
3
)
Cylinder Diameter / Stroke: 37 mm / 30 mm (1.46 in / 1.18”)
Compression Ratio: 7.8 : 1
Gas : Oil Ratios: 25 - 30 : 1 Break-in Trial Run; 40 – 50 : 1 Normal Flying
Weights: Engine 57.1 oz, Muffler: 2.3 x 2 ea oz, Ignition 4.76 oz
DLA 64-I2cc (3.91 in
3
) Gas Engine (In-Line)
Power: 7.6 @ HP @ 8500 rpm
Idle Speed: 1,400 rpm
Static Thrust: 35 pounds @ 100 m (~328 ft) (Pulling Force)
31 pounds @ 1,800 m (~5,900 ft)
Propellers: 22 x 10, 23 x 8/10, 24 x 8
Carburetor: Walbro™. “WT-xxx” Series
CDI Voltage: 6.4 – 8.4 VDC
Spark Plug: CM-6 Special, Iridium
