> 81 pounds @ 1,800 m (~5,900 ft)
Propellers: 32 x 10 / 12 / 14, 33 x 10
Carburetor: Walbro™, “WT-xxx” Series
CDI Voltage: 6.4 – 8.4 VDC
Spark Plug: CM-6 Special, Iridium
Exhaust Volume: 180 cc (10.98 in
3
)
Cylinder Diameter / Stroke: mm / mm (in /in)
Compression Ratio: 7.8 : 1
Gas : Oil Ratios: 25 – 30 : 1 Break-in Trial Run; 40 – 50 : 1 Normal Flying
Weights: Engine: 129.0 oz (8.1 lbs); Muffler: oz; Ignition: oz
DLA 232cc (14.6 in
3
) Gas Engine
Power: > 23 HP @ 7,500 rpm
Idle Speed: ~ 1,150 rpm
Static Thrust: >100 pounds @ 100 m (~328 ft) (Pulling Force)
> 90 pounds @ 1,800 m (~5,900 ft)
Propellers: 34 x 10, 35 x 10/12, 36 x 10 2-Blade, 28x14, 30x12, 32x12 3-Blade
Carburetor: Walbro™, “WT-xxx” Series
CDI Voltage: 6.4 – 8.4 VDC
Spark Plug: CM-6 Special, Iridium
Exhaust Volume: 232 cc (14.6 in
3
)
Cylinder Diameter / Stroke: mm / mm (in /in)
Compression Ratio: 7.8 : 1
Gas : Oil Ratios: 25 – 30 : 1 Break-in Trial Run; 40 – 50 : 1 Normal Flying
Weights: Engine: 172.8 oz; Muffler: 15.8 oz; Ignition: 15.2 oz
Engine Bolt Torques:
DLA 32 DLA 56 / 58 DLA 64 DLA 112 / 116 DLA 128cc
Prop-Bolts 40 62 62 80 80
Prop-Shaft Extension 257 296 301 301 301
Crank-Case Bolts 80 106 124 124 124
Spark Plug 90 90 90 90 90
Head / Cylinder Bolts 80 106 97 106 97
Carburetor Bolts 53 62 62 62 62
Muffler Bolts
Engine Mounting
Spark Plug Gap 0.18" 0.18" 0.18" 0.18" 0.18"
Ignition Sensor
Advance (Degrees)
~30⁰ ~30⁰ ~30⁰ ~30⁰ ~30⁰
Other
DLA Engines Bolt TORQUES (inch * lbs)
