DLA 58cc - Parts List

GS R/C
DLA ENGINE OPERATING-INSTRUCTION
MANUAL
06/29/2016 Copyrighted Material
Owner’s Manual All Rights Reserved 03180-10000
Page - 35 DLA 32, 58, 64, 64-I2, 116, 116-I2 & 128cc, 180c, 232cc Rev. A.05.11
PARTS LIST 58cc: (See www.goldenskiesrc.com for current lists and Prices)
DLA 58
Dwg
Key #
Part Description
03180-01205 1
Cylinder Head, 58cc, Straight Plug Config
03180-01206 2 Crankshaft & Connecting Rod, 58cc
03180-01207 3 Crank Case, Front & Rear, 58cc
03180-01208 4 Piston & Wrist Pin w /retainers, 58cc
03180-01209 5 Ring, Piston, 58cc
03180-01210 6 Ignition Module, 58cc, Capacitive Discharge.
03180-01211 7
Muffler, Std-CAN, 58cc
03180-01212 8 Carburetor, 58cc, Complete, Walbro WT-247
03180-01213 9 Standoffs, Engine Mounting, & Bolts, 58cc
03180-01214 10 Spark Plug, Iridium, all engines
03180-01215 11 Reed Valve Assembly, Carburetor, 58cc
03180-01216 12
Bearing Set, Front & Rear, Crankshaft, (FAG), 58cc
03180-01217 13 Sensor, Ignition, w/mounting screws
03180-01218 14 Gasket Set, Muffler, Carburetor, Head, 58cc
03180-01219 15 Bolt Set: Mounting, Muffler, Prop, 58cc
03180-01220 16 Hub, Propeller, Washer, Propeller, 58cc
03180-01221 17 Bearing Needle, Connecting-rod wrist-pin, 58c / 116cc / 232cc, 13mm
03180-01222 18 Wrist-Pin, Piston, , Con-rod, 58 / 116cc
03180-01223 19 Puffer - Line, Carb to Reed Valve Assembly
03180-01224 20 Bushing-Spacer, Crankshaft, forward
03180-01225 21 Propeller Shaft, Crankshaft Extension, 58cc
03180-01226 22 Retainers, Piston Pin
03180-01227 23
Reserved
03180-01228 5B
Rings, BOWMAN, 58cc / 116cc / 232cc
03180-01229 -- Reserved
03180-01230 -- Gasket, Cylinder Head, 58cc / 116cc / 232cc
03180-01231 -- Gasket, Carburetor, 58cc
03180-01232 -- Reserved
03180-01233 -- Key, Woodruff
03180-01234 -- Gasket, Muffler, 58cc / 116cc / 232cc
03180-01235 --
Reserved
03180-01236 --
Prop Washer, Only, 58cc
03180-01237 --
Prop-Hub (Only), 58cc
03180-01238 -- Bolts, Muffler, 500 x 0.8 - 16 mm, (2 ea)
01380-01144
--
Muffler, Pitts Style, 58cc
01380-01239 -- Tachometer
01380-01240 -- Diaphragm Repair Kit, WT-805
01380-01241 -- Gasket, New Style, & Bolts / Lock washers, 58cc
01380-01242 -- Repair Kit, Carburetor: WT-805
01380-01243 1S
Cylinder Head, 58cc, Slanted Spark Plug Configuration
03180-01245
Muffler, Canister, 58cc
DLA 58cc PARTS LIST - Rev: A.06
Part Numbers - Engine Components
