DLI 8 Product Manual Rev. 1
Front Panel
Back Panel
The I/O ports and power supply connector are located on the back of the unit.
Power Supply Connector
The connector is to be used with the DLI series of power supplies. Please see below for a
reference of recommended power sources.
The Cradle can be powered by an external DC power source of 18VDC~22VDC.
Verify that the power source is always within the specification range and
observe correct input voltage polarity. An improper input voltage range
above 22VDC or reverse polarity could damage the power conversion
circuitry.
Recommended Power Supplies:
5400011 AC Adapter W/Line Cord
6700040 Device Cigarette Lighter Adapter w/ Standard Adapter
(12-24 DC Input)
3431182037500P Power Cable, 3 Prong Locking Connector, 12’ w/ 10A Fuse &
(Bare Leads) For use with Vehicle Cradle
Quick Lock & Release Arms
