29
Manual No. 4111-0025
March 2011
May 2012
PARTS
ITEM QTY SIZE/CAPACITY DESCRIPTION PART NUMBER (15”) LIP PART NUMBER (17”LIP)
1
1 6620/25 Lip Plate & Hinge Assembly DOTH-4047 DOTH-4048
1 6630 Lip Plate & Hinge Assembly DOTH-4049 DOTH-4050
1 6635 Lip Plate & Hinge Assembly DOTH-4051 DOTH-4052
1 7220/25 Lip Plate & Hinge Assembly DOTH-4053 DOTH-4054
1 7230 Lip Plate & Hinge Assembly DOTH-4055 DOTH-4056
1 7235 Lip Plate & Hinge Assembly DOTH-4057 DOTH-3167
1 7820/25 Lip Plate & Hinge Assembly DOTH-4058 DOTH-4059
1 7830 Lip Plate & Hinge Assembly DOTH-3924 DOTH-4060
1 8420/25 Lip Plate & Hinge Assembly DOTH-3156 DOTH-3155
1 8430 Lip Plate & Hinge Assembly DOTH-3159 DOTH-4061
2
1 6620/25 Center Plate & Hinge Assembly DOTH-4062
1 6630 Center Plate & Hinge Assembly DOTH-4063
1 6635 Center Plate & Hinge Assembly DOTH-4064
1 7220/25 Center Plate & Hinge Assembly DOTH-4065
1 7230 Center Plate & Hinge Assembly DOTH-4066
1 7235 Center Plate & Hinge Assembly DOTH-3258
1 7820/25 Center Plate & Hinge Assembly DOTH-4067
1 7830 Center Plate & Hinge Assembly DOTH-3923
1 8420/25 Center Plate & Hinge Assembly DOTH-3242
1 8430 Center Plate & Hinge Assembly DOTH-3241
3 1 ALL Base Plate & Hinge Assembly Consult Factory
4
2 6620/25/30 Hinge Pin DOTH-3104
2 6635 Hinge Pin DOTH-4312
2 7220/25/30 Hinge Pin DOTH-3122
2 7235 Hinge Pin DOTH-4313
2 7820/25/30 Hinge Pin DOTH-3946
2 8420/25/30 Hinge Pin DOTH-3920
5 2 All Rivet - Button DOTH-2400
6 2 All Rivet - Flat DOTH-2398
7 2 All Extra Hvy Duty Bumper Blocks DBBS-3500
8
1 6620/25/30, 7220/25 Spring Linkage Assy - X-Regular DOTH-3618
1
6635,7230,7820/25,
8420/25
Spring Linkage Assy - X-Hvy Duty DOTH-3630
1 7235, 7830/35, 8430 Spring Linkage Assy - 3 Spring DOTH-3626
9 2 All X-Gusset DOTH-3589
10 - All Secondary Gussets DOTH-3319
11
1 66/7220-30 NL Roller Arm Assembly - Open DOTH-3834
1 78/84 NLIII Operating Link Assembly DOTH-3696
1 35K Only NLIII Operating Link Assembly DOTH-3697
12
1 66/7220-30 NL Pipe Handle Assembly DOTH-3833
1 66/7235 - 78/84 NLIII Hanlde Assembly DOTH-3694
13 1 All Extend Link Arm DOTH-3585
14 1 All Extend Link Arm Stop DOTH-3586
15 2 All Pivot Block DOTH-3316
16 1 All Shoulder Bolt DOTH-2061
17 1 All Locknut DOTH-2136
18 1 All Lip Stop DOTH-3734
19 1 All NLIII Handle Holder DOTH-3695
To Next Page
