31
Manual No. 4111-0025
March 2011
May 2012
PARTS
ITEM QTY SIZE/CAPACITY DESCRIPTION PART NUMBER (15”) LIP PART NUMBER (17”LIP)
1
1 6620/25 Lip Plate & Hinge Assembly DOTH-4068 DOTH-4069
1 6630 Lip Plate & Hinge Assembly DOTH-4070 DOTH-4071
1 6635 Lip Plate & Hinge Assembly DOTH-4072 DOTH-4073
1 7220/25 Lip Plate & Hinge Assembly DOTH-4074 DOTH-4075
1 7230 Lip Plate & Hinge Assembly DOTH-4076 DOTH-4077
1 7235 Lip Plate & Hinge Assembly DOTH-4078 DOTH-4079
1 7820/25 Lip Plate & Hinge Assembly DOTH-4080 DOTH-4081
1 7830 Lip Plate & Hinge Assembly DOTH-4082 DOTH-4083
1 8420/25 Lip Plate & Hinge Assembly DOTH-4084 DOTH-4085
1 8430 Lip Plate & Hinge Assembly DOTH-4086 DOTH-4087
2
1 6620/25 Center Plate & Hinge Assembly DOTH-4088
1 6630 Center Plate & Hinge Assembly DOTH-4089
1 6635 Center Plate & Hinge Assembly DOTH-4090
1 7220/25 Center Plate & Hinge Assembly DOTH-4091
1 7230 Center Plate & Hinge Assembly DOTH-4092
1 7235 Center Plate & Hinge Assembly DOTH-4093
1 7820/25 Center Plate & Hinge Assembly DOTH-4094
1 7830 Center Plate & Hinge Assembly DOTH-4095
1 8420/25 Center Plate & Hinge Assembly DOTH-4096
1 8430 Center Plate & Hinge Assembly DOTH-4097
3 1 ALL Base Plate & Hinge Assembly Consult Factory
4
2 6620/25/30 Hinge Pin DOTH-3104
2 6635 Hinge Pin DOTH-4312
2 7220/25/30 Hinge Pin DOTH-3122
2 7235 Hinge Pin DOTH-4313
2 7820/25/30 Hinge Pin DOTH-3946
2 8420/25/30 Hinge Pin DOTH-3920
5 2 All Rivet - Button DOTH-2400
6 2 All Rivet - Flat DOTH-2398
7 All Extra Hvy Duty Bumper Blocks DBBS-3500
8 2 All HL LInkage Adder Assembly DOTH-3675
9 2 All X-Gusset DOTH-3589
10
1 66/7220-30 NLI Operating Link Assembly DOTH-3726
1 78/84 NLIII Operating Link Assembly DOTH-3696
1 35K Only NLIII Operating Link Assembly DOTH-3697
11
1 66/7220-30 NLI Handle Assembly (Tube) DOTH-3752
1 Optional NLI Handle Assembly (Solid) DOTH-3769
1 78/84 NLIII Handle Assembly DOTH-3694
12 1 All Extend Link Arm DOTH-3585
13 1 All Extend Link Arm Stop DOTH-3586
14 2 All Pivot Block DOTH-3316
15 1 All Shoulder Bolt DOTH-2061
16 1 All Locknut DOTH-2136
17 1 All Lip Stop DOTH-3734
18 1 All Pivot Block DOTH-3597
19 2 All Cotter Pin DOTH_2375
20 1 All Spring DOTH-2559
21 1 All NLIII Handle Holder DOTH-3695
To Next Page
