Placement in the room
The Flatsub Stereo-One is designed for hanging on a wall. A wall bracket
is included with the Flatsub Stereo One. The wall bracket is attached
on the wall as in the drawing below.
Another way is to place it lying under a furniture, for example a sofa.
Horisontal or vertical placement on the wall
The hanging direction of Flatsub Stereo-One can be changed by moving
the wall bracket as described below.
1. This photo shows the original placing of the wall bracket. Fig 1.
2. Remove the bracket by removing it from the rear side using a
T30 torx screw driver.
Remove the lower right (or left)removable foot. See figure. 1& 2
3. Remount the bracket and adjustable foot as in figure 3.
Choose the alternative that suits the wall and your taste.
Horizontal adjustmentVertical adjustment
Wall bracket
Fig.3
Fig.1
Fig.2
Contact:
DLS Svenska AB
P.O. Box 13029,
SE-402 51 Göteborg
SWEDEN
Phone: +46 31 840060,
Fax: +46 31 844021
e-mail: info@dls.se, www.dls.se
Copyright
©
DLS Svenska AB. All rights reserved
Remove
Remove
Remount the
bracket here
Remount the
foot here
